Bachmann SEM201 is a SERCOS master module developed for the Bachmann M1 and M200 automation controller platforms. The module provides deterministic real-time communication between the controller and distributed servo drives using the SERCOS II protocol according to IEC 61491. It is primarily used in motion control systems requiring synchronized multi-axis drive communication with high transmission stability.
SEM201 uses fiber optic ring topology for communication between the master controller and connected servo amplifiers. The module supports up to 32 drives per network segment and allows synchronization of multiple masters within larger automation architectures. Typical applications include turbine control systems, high-speed manufacturing machinery, coordinated motion platforms, packaging systems, and industrial robotics.
The module exchanges cyclic process data and supports acyclic parameter access through the SERCOS service channel. Fiber optic transmission improves EMC immunity and electrical isolation in electrically noisy industrial environments.
| Parameter | Value |
|---|---|
| Model | SEM201 |
| Brand | Bachmann |
| Product Type | SERCOS Master Module |
| Series | M1 / M200 Control System |
| Communication Protocol | SERCOS II (IEC 61491) |
| Communication Medium | Fiber Optic |
| Bus Structure | Ring Topology |
| Supported Drives | Up to 32 Drives |
| Transfer Rates | 2 / 4 / 8 / 16 MBaud |
| Cycle Times | 62.5 μs to 65 ms |
| DPRAM | 2 Kb × 32 |
| Synchronization | Multiple Masters Supported |
| Galvanic Isolation | Yes, via Fiber Optic Interface |
| Modules per Controller | Maximum 12 |
| Operating Temperature | 0 to +60 °C |
| Storage Temperature | -40 to +85 °C |
| Humidity | 5–95% Non-condensing |
| Interface Type | 2 × FSMA Fiber Optic (In/Out) |
| Origin | Austria |
Data compiled from Bachmann technical documentation and fieldbus module specifications.
Model: SEM201
Part Number: 00011756-00
Product Description: SERCOS Master Module
Communication Standard: SERCOS II
Manufacturer: Bachmann electronic GmbH
SEM201 integrates directly into the Bachmann controller rack and operates as a dedicated motion communication interface. The module uses dual fiber optic ports for ring-based SERCOS communication. During startup, the controller distributes configuration parameters to connected drives and establishes synchronized cyclic data exchange.
The module supports standardized drive object access and runtime parameter modification through the SERCOS service channel. Multiple SEM201 modules can operate in synchronized controller architectures where coordinated axis control is required.
Fiber optic connectors should be inspected carefully during installation to prevent contamination or attenuation losses. Excessive bending radius on optical cables can cause intermittent communication faults under high-speed transmission conditions. Cabinet routing should separate power cables from signal and fiber optic paths to reduce EMC coupling into adjacent equipment.
When replacing an SEM201 module, verify identical SERCOS baud rate settings and network addressing before commissioning. Drive initialization timing should also be checked after replacement, especially in synchronized multi-axis systems. Spare modules should be stored in anti-static packaging and protected from moisture exposure during long-term inventory storage.
Q1: What SERCOS standard does the SEM201 support?
The module supports SERCOS II communication according to IEC 61491.
Q2: How many drives can SEM201 control?
One SEM201 module can control up to 32 SERCOS drives.
Q3: Does the module support fiber optic communication only?
Yes. SEM201 uses fiber optic ring topology with FSMA optical interfaces.
Q4: Can multiple SEM201 masters operate together?
Yes. Multiple masters can be synchronized for coordinated motion applications.
Q5: What is the typical industrial use of SEM201?
The module is commonly used in servo motion control systems, turbine automation, robotics, and synchronized industrial drive networks
