Manufacturer: BECKHOFF
Product No.: C6140-0060
Country of origin:Germany
Product Type: Control Cabinet Industrial PCs
Payment: T/T, Western Union
Weight: 14000g
Dimensions: 383 mm x 362 mm x 265 mm
Shipping port: Xiamen
Warranty: 12 months
For demanding industrial control tasks, the Beckhoff C6140-0060 provides a robust, cabinet-mounted processing platform. This 7-slot ATX Industrial PC is engineered for installation within control cabinets, presenting all connection interfaces on the top of the unit for simplified wiring and easy access. With a physical layout optimized for high availability, operators can easily access drives and plug-in expansion cards. The front panel provides clear system status via integrated LEDs and a protected manual reset key, alongside detailed hardware configuration labels.
The core ATX motherboard architecture of the C6140-0060 is compatible with 4th generation Intel processors, spanning from dual-core Pentium units up to high-performance quad-core Core i7 configurations. This scaling aligns directly with TwinCAT 3 (TC3) performance classes (ranging from TC3: 50 up to TC3: 80), enabling precise resource matching for PLC, CNC, and motion control applications. Built-in tool-free card holders secure expansion modules against industrial vibration while speeding up maintenance and hardware updates.
| Beckhoff |
| C6140-0060 |
| Control Cabinet Industrial PC |
| 7-slot ATX Industrial PC |
| Intel Pentium G3320TE 2.3 GHz (2 Cores, TC3: 50) |
| 4th Generation Intel Core i3, i5, or i7 |
| 2 GB DDR3L RAM (expandable up to 32 GB) |
| Intel integrated graphics with 2 x DVI and 1 x DisplayPort interfaces |
| 2 x PCIe x1, 1 x PCIe x4, 1 x PCIe x16, 3 x PCI |
| Up to 270 mm length (PCI slots), up to 240 mm length (PCIe slots) |
| 3.5-inch 1 TB Hard Disk Drive (HDD) with on-board SATA RAID 1 support |
| Dual 100/1000BASE-T on-board Ethernet controller (2 x RJ45) |
| 4 x RS232 on-board (1 external D-sub 9 connection) |
| 10 x USB 2.0 (2 external ports), 2 x USB 3.0 (external ports) |
| PS/2 keyboard socket, PS/2 mouse socket |
| 100 to 240 V AC full range |
| IP20 |
| 0 to 55 degC |
| 383 mm x 362 mm x 265 mm |
| 14 kg (basic configuration) |
| Interface Type | Connection Interface Details |
|---|---|
| 2 x RJ45 Gigabit Ethernet ports (100/1000BASE-T) | |
| 2 x DVI ports, 1 x DisplayPort | |
| 2 x USB 3.0 Type-A, 2 x USB 2.0 Type-A | |
| 1 x RS232 (D-sub 9-pin male connector) | |
| PS/2 keyboard and mouse ports |
