BECKHOFF CP2718-0020 Fanless Multi-Touch Built-in Panel PC

SKU CP2718-0020

In stock

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: CP2718-0020
Origin Germany
Product Type: Industrial Panel PCs
Payment: T/T, Western Union
Weight: 0.5 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The BECKHOFF CP2718-0020 is an industrial-grade, fanless built-in Panel PC designed for demanding visualization and control tasks in automated environments. Engineered as a highly durable human-machine interface (HMI), this device combines processing capabilities with an integrated display, making it ideal for installation in the front of control cabinets or control desks.

Equipped with an 18.5-inch multi-finger capacitive touch screen at a resolution of 1366 x 768, the BECKHOFF CP2718-0020 provides an intuitive user interface with reliable optical performance. The mechanical construction features a rugged aluminum housing with a glass front, designed to withstand standard industrial operating conditions while offering front-side IP65 ingress protection.

The internal architecture is powered by the energy-efficient Intel Atom® x5-E39xx processor series on a compact 3½-inch motherboard. Dual CFast slots serve as primary solid-state storage, ensuring reliable boot times and high resistance to shock and vibration. With multiple onboard communication interfaces, including Gigabit Ethernet and USB, this panel PC integrates into EtherCAT-based control environments and plant networks.

Features

18.5-inch multi-finger touch display with a 1366 x 768 resolution.
Fanless design with low-power Intel Atom® processors for maintenance-free operation.
Rugged aluminum housing with front-side IP65 and rear-side IP20 protection ratings.
Two CFast slots for secure, solid-state system and storage management.
Pull-out clamping levers for fast cabinet installation without loose mounting hardware.
Onboard dual 100/1000BASE-T Gigabit Ethernet interfaces for high-speed industrial networking.
Integrated interfaces including USB 3.0, USB 2.0, and a DVI connector.

Applications

Machine-level visualization and operator control interface for packaging and assembly lines.
Central control terminal for manufacturing cells utilizing TwinCAT automation platforms.
Industrial data acquisition, monitoring, and remote diagnostics stations.
Process control cabinet displays requiring low heat generation and fanless hardware reliability.

Technical Specifications

Display and Housing

Display Size and Resolution	18.5-inch, 1366 x 768 pixels
Touch Technology	Multi-finger touch screen (capacitive)
Housing Material	Aluminum housing with glass front
Protection Rating	Front side IP65, rear side IP20

Processing and Memory

Processor Options	Intel Atom® x5-E3930 (1.3 GHz, 2 cores) or Intel Atom® x5-E3940 (1.6 GHz, 4 cores)
Motherboard	3½-inch motherboard for Intel Atom® x5-E39xx
Memory (RAM)	4 GB DDR4 RAM (up to 8 GB DDR4 RAM ex factory)
Storage Media Slots	2 x slots for CFast cards (40 GB to 320 GB CFast options)

Interfaces and Connectivity

Onboard Ethernet	2 x 100/1000BASE-T on-board ports
USB Ports	2 x USB 3.0, 2 x USB 2.0
Video Output	1 x DVI interface

Electrical and Environmental

Power Supply	24 V DC (optional UPS integration support)
Operating Temperature	0 to 55 degC
Operating System Compatibility	Windows 10 IoT Enterprise

Installation Guidelines

Verify that the control cabinet cutout matches the exact dimensions required for the 18.5-inch CP2718-0020 housing.
Ensure that the installation area and power supplies are completely de-energized before beginning installation.
Insert the Panel PC into the cutout from the front side, ensuring the sealing gasket is correctly seated for IP65 protection.
Tighten the integrated pull-out clamping levers from the rear to secure the device to the cabinet wall. Do not over-torque.
Connect the system ground connection to the housing ground terminal to protect against electromagnetic interference.
Connect the 24 V DC power supply lines and desired network, communication, and peripheral cabling before powering up.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary display configuration of the BECKHOFF CP2718-0020?

The BECKHOFF CP2718-0020 features an 18.5-inch multi-finger capacitive touch screen with a high-definition resolution of 1366 x 768.

Is the BECKHOFF CP2718-0020 equipped with internal cooling fans?

No, the BECKHOFF CP2718-0020 is designed with a fanless cooling architecture, making it highly reliable and maintenance-free in dusty or harsh industrial settings.

What protection class is supported by the BECKHOFF CP2718-0020?

The BECKHOFF CP2718-0020 provides IP65 protection on its front display panel when correctly installed in a cabinet, and an IP20 rating on the rear chassis.

What storage options are available on the BECKHOFF CP2718-0020?

The BECKHOFF CP2718-0020 contains two internal slots for CFast cards, offering reliable and shock-resistant solid-state storage.

How is the BECKHOFF CP2718-0020 physical unit mounted?

The BECKHOFF CP2718-0020 utilizes built-in pull-out clamping levers on the rear, allowing rapid mounting into a standard control cabinet panel cutout without loose parts.
