Description

The BECKHOFF CP2721-0010 is a built-in Panel PC engineered for industrial human-machine interface (HMI) applications. Combining high-resolution visualization and processing in a single unit, this fanless device is designed to be installed directly in the front of control cabinets or control desks. Its integrated design optimizes space utilization while maintaining complete control functionality on the factory floor.

At the core of the BECKHOFF CP2721-0010 is a modern multi-touch interface paired with a 21.5-inch display. The unit uses a 3½-inch motherboard designed for Intel Atom processors, achieving a balance of computational efficiency and low power consumption. This architecture allows the Panel PC to operate without active fan cooling, minimizing maintenance overhead and eliminating dust accumulation risks inside the enclosure.

Equipped with dual CFast slots and integrated communication interfaces, the Panel PC serves as a reliable platform for TwinCAT-based control systems. The front face is protected against dust and liquids, making it suitable for rigorous operation in manufacturing, assembly, and process control environments.

Features

• Widescreen 21.5-inch display with multi-finger touch capability.
• Completely fanless operation with no moving parts to enhance operational life.
• Dual CFast storage slots for solid-state reliability and easy data separation.
• Integrated Gigabit Ethernet interfaces for high-speed network integration.
• Front panel certified with high ingress protection (IP65) for wet and dusty environments.
• Convenient cabinet mounting system using pull-out clamping levers.

Applications

• Operator panels and HMI stations on manufacturing and assembly lines.
• Control cabinet-integrated supervisory control and data acquisition (SCADA).
• Process visualization and parameter adjustment terminals.
• Machine-level industrial automation environments running TwinCAT runtime systems.

Technical Specifications

General and Display

System Architecture

Electrical and Interfaces

Mechanical and Environmental

Installation Guidelines

1. Ensure all power supplies are fully de-energized before beginning installation or wiring.
2. Prepare a precise cutout in the control cabinet door or panel according to the exact dimensional drawing for the 21.5-inch enclosure.
3. Carefully insert the Panel PC from the front into the prepared cutout.
4. Engage and tighten the pull-out clamping levers from the rear to secure the device. Ensure even pressure to establish a reliable IP65 seal against the front panel surface.
5. Ensure that the IP20 rear housing has adequate clearance for passive convective cooling and that the ventilation pathways are unobstructed.
6. Connect the 24 V DC power supply and ground conductors in accordance with electrical engineering standards.
7. Attach Ethernet, USB, and any other system cables before applying control voltage.
