BECKHOFF

Beckhoff CP3212-0020 CP32xx Series Multi-touch Panel PC

SKU CP3212-0020

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: BECKHOFF

  • Product No.: CP3212-0020

  • Country of origin:Germany

  • Product Type: Multi-touch Panel PCs

  • Payment: T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

Engineered for direct machine-level integration, the Beckhoff CP3212-0020 combines an industrial-grade multi-touch panel with a high-performance 3.5-inch motherboard housed in a robust, pole-mounted enclosure. This control unit is optimized for mounting arm installation, enabling operators to access complex HMI and control functions directly at the machine face. Powered by 6th and 7th generation Intel processors, the CP3212-0020 delivers reliable computing performance for resource-intensive automation tasks, while its advanced thermal management systems maintain structural integrity and system reliability in challenging plant environments.

Key Features

  • Rugged Aluminum Enclosure: Designed for mounting arm installation with a rotatable and tiltable adapter compatible with Rittal and Rolec 48 mm tube systems.
  • Multi-Touch Capability: Equipped with a projective capacitive multi-finger touch screen for intuitive and precise operator input.
  • Optimized Thermal Design: Passive cooling via an external heat sink, supplemented by an internal fan to ensure uniform heat distribution across all housing walls.
  • Expandable Storage & Slots: Offers configurable slots for 2.5-inch SSDs, CFast cards, and a PCIe module slot for peripheral expansions.
  • Industrial Protection: Full IP65 rating shielding the internal electronics from dust, moisture, and low-pressure water jets from all directions.

Applications

  • Machine-Level HMI: Direct integration onto packaging lines, CNC machinery, and assembly systems.
  • Automotive Assembly: Real-time visualization and control stations along assembly bays requiring articulating arm mounts.
  • Process Control Monitoring: Distributed control operations in environments needing washdown-resistant operator interfaces.

Technical Specifications

Parameter Specification
Manufacturer Beckhoff
Model Number CP3212-0020
Display Size 12-inch Display
Touch Technology Projective Capacitive Multi-Touch (PCT)
Housing Material Aluminum housing with IP65 protection
Mounting Integration Rotatable and tiltable mounting arm adapter for Rittal/Rolec 48 mm tube from top/bottom
Motherboard Form Factor 3.5-inch Industrial Motherboard
Supported Processors Intel Celeron, Pentium, Core i3, Core i5, or Core i7 (6th/7th Generation)
Memory Support 4 GB to 32 GB DDR4 RAM
On-board Ethernet 2 x 100/1000BASE-T on-board ports
Power Supply 24 V DC (Optional UPS integration)
Operating Temperature 0 to 45 degC
Country of Origin Germany
Shipping Weight (Calculated) 5.0 kg

Empirical Engineering Insights

Alternative Models & Compatibility

The CP3212-0020 utilizes the CP32xx series multi-touch architecture. When configuring replacement units, pay close attention to the TwinCAT software generation requirements: Celeron G3900TE processors scale within TwinCAT 2/3 performance class 50, whereas upgraded Core i7 profiles escalate processing requirements to TwinCAT 3 performance class 80 licenses. Interface compatibility with existing cabling systems should be verified against the 1 x Ethernet 100/1000BASE-T push-pull configuration.

Application Pitfalls & Engineering Notes

For effective heat management, passive cooling requires a minimum clearance of 20 cm (7.9 inches) of free space for air circulation around the enclosure. Operating close to the 45 degC limit without this volume restriction can trigger CPU thermal throttling, potentially degrading PLC cycle performance. Ensure the internal circulation fan is clean and unobstructed to avoid localized hot spots inside the aluminum structure.

Commissioning & Wiring Tips

The wiring compartment supports up to six IP65-sealed industrial connectors. When passing cables through the mounting arm, route high-voltage lines separately from Ethernet and signal cables to limit EMI induction. For applications with critical uptime, utilize the 24 V DC power configuration with an external UPS to prevent database and state-machine corruption during sudden utility supply drops.

Installation Guidelines

CRITICAL WARNING: Isolate all electrical power sources before commencing installation or maintenance. Verify the structural integrity and weight capacity of the supporting mounting arm system before locking the 48 mm adapter.
1

Mount the CP3212 unit safely onto the 48 mm Rittal or Rolec mounting arm tube, securing the locking screws to the required torque specification.

2

Route the connection cables through the internal space of the mounting arm directly into the integrated IP65 wiring area of the Panel PC.

3

Secure all active IP65 connectors, verifying the sealing rings are fully seated to maintain the environmental ingress protection level.

4

Apply 24 V DC power and confirm the operating system boots normally. Set display parameters and calibrate touch interfaces if necessary.

FAQ

What mounting systems are compatible with the CP3212-0020?
This Panel PC features an integrated, rotatable, and tiltable adapter designed for 48 mm tube mounting arm systems manufactured by Rittal and Rolec, supporting insertion from either the top or bottom.

Does the CP3212-0020 have a fan, and how is it cooled?
The system utilizes passive cooling through an integrated external heat sink structure. However, an internal fan is installed to distribute heat evenly to all interior housing walls, preventing localized heat build-up.

What are the ventilation clearance requirements for this Panel PC?
To ensure reliable thermal performance and avoid processor throttling, a minimum of 20 cm (7.9 inches) of open air circulation space is required around the entire PC housing.

What degree of environmental protection does the enclosure provide?
The CP3212-0020 features a fully enclosed IP65-rated aluminum housing, protecting internal components against dust ingress and low-pressure water jets from any direction when cables are correctly sealed.
