Beckhoff CP3215-0020 CP32xx Multi-touch Panel PC

Only 10 item(s) left in stock

Manufacturer: BECKHOFF
Product No.: CP3215-0020
Country of origin:Germany
Product Type: Multi-touch Panel PCs
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months

Description

Engineered as a robust high-performance control and HMI platform, the Beckhoff CP3215-0020 integrates direct-machine-level visualization with heavy-duty industrial computing. Built to withstand demanding factory floor environments, this industrial panel PC features a fully enclosed aluminum housing with IP65 protection, designed specifically for mounting arm systems. The unit supports versatile processing capacities from 6th and 7th generation Intel processors and pairs this processing power with advanced projective capacitive multi-touch technology, making it ideal for high-performance TwinCAT-controlled manufacturing environments.

Key Features

All-Around Ingress Protection: Fully sealed aluminum housing rated to IP65 standards, protecting against dust and liquid jet penetration from any angle.
Ergonomic Mounting System: Integrates a rotatable and tiltable mounting arm adapter compatible with Rittal and Rolec 48 mm tube configurations (flexible entry from top or bottom).
Reliable Thermal Engineering: Features a thermal management system combining passive heat sink fins with an internal circulation fan for balanced heat distribution.
Industrial Motherboard Design: Built on a standard 3.5-inch motherboard architecture supporting modular system memory upgrades up to 32 GB DDR4 RAM.
Modular Storage Capabilities: Equipped with dedicated slots supporting 2.5-inch SSDs/HDDs alongside dual CFast slot expansion.

Applications

High-end automotive assembly line visualization and process tracking.
Continuous process control and packaging machine monitoring.
Food, beverage, and chemical plant environments requiring frequent washdown-rated hardware.
Distributed machinery control requiring direct HMI integration via robust mounting arm installations.

Technical Specifications

Manufacturer	Beckhoff Automation
Model Reference	CP3215-0020
Display Size	15-inch display (1024 x 768 resolution)
Touch Technology	Projective capacitive multi-finger touch screen
Processor Support	Intel Celeron G3900TE 2.3 GHz up to Core i7 7700(T) 2.9 GHz
Motherboard	3.5-inch industrial form factor (6th/7th Gen Intel Core architecture)
Memory Configuration	4 GB DDR4 RAM base configuration (expandable up to 32 GB)
Onboard Ethernet	2 x 100/1000BASE-T on-board controllers
SATA Controller	On-board SATA RAID 1 controller
Storage Interfaces	1 x 2.5-inch HDD/SSD slot, up to 2 x CFast card slots
Power Input	24 V DC (UPS functional input compatible)
Ingress Protection Rating	IP65 (Full protection against dust ingress and liquid jets)
Operating Temperature	0 to 45 Celsius
Required Clearance	20 cm (7.9 inches) free air circulation space around enclosure
TwinCAT Performance Class	TC2/TC3: 50 (up to TC3: 80 depending on CPU selection)
Country of Origin	Germany
Shipping Weight (Calculated)	5.0 kg (11.02 lbs)

Connections and Interfaces

Port / Interface Type	Functional Details / Connectivity
Network Connection	1 x Ethernet 100/1000BASE-T Push-Pull IP65 rated port
On-board Ports	2 x RJ45 100/1000BASE-T (internal/service routing)
IP65 Connection Area	Capable of managing up to 6 IP65-rated connectors (4 slots left unassigned for customization)
Power Supply Inlet	24 V DC main connection terminal block with support for UPS diagnostic feedback

Empirical Engineering Insights

Alternative Models & Compatibility

The system's modular 3.5-inch motherboard allows flexible configuration swaps. However, upgrading from an Intel Celeron configuration to a Core i7 processor will transition the system's TwinCAT 3 performance class from Level 50 to Level 80. Ensure that your TwinCAT licensing scheme matches the installed hardware configuration to prevent software runtime locking.

Application Pitfalls & Engineering Notes

To guarantee continuous industrial operation at maximum computing load without CPU thermal throttling, you must maintain a physical 20 cm (7.9 inches) radial clearance around the chassis. Obstructing the rear passive heat sink profile will force the internal cooling fan to run continuously at full capacity, shortening the component service life.

Commissioning & Wiring Tips

When connecting interfaces inside the wiring compartment, ensure that all unused entry ports remain sealed with the original IP65 protection blanks. To maintain electrical safety and prevent high-frequency touch interference on the capacitive surface, establish a low-impedance connection between the mounting arm ground and the plant ground plane.

Installation Guidelines

CRITICAL WARNING: De-energize all power lines feeding the system before opening the IP65 interface routing cover. Verify the 24 V DC power feed is completely isolated from the main supply grid. Ensure system ground is connected before energizing internal components to prevent permanent damage from electrostatic discharge (ESD).

Mechanical Mounting: Securely align the 48 mm mounting arm adapter to the Rittal or Rolec support system from the top or bottom as required. Tighten safety lock-screws to the specified torque.

Cable Routing: Feed supply voltage, network lines, and peripheral connections through the hollow section of the 48 mm mounting tube and direct them into the wiring area.

Electrical Connections: Connect the 24 V DC power cables securely to the internal terminal block. Connect the industrial push-pull Ethernet cable to the main RJ45 port.

Sealing and Torque: Close the wiring interface area cover, ensuring the integrated gasket is seated flat without twists. Tighten the cover screws in a cross pattern to secure the IP65 moisture barrier.

Product Image	Model Number / Title	Condition	Availability	Action
	ABB 3BSE042238R1 PP846A Panel 800 Operator Panel	Original New	In Stock	View Details
	Woodward 9907-1183 505E Human-Machine Interface	Original New	In Stock	View Details

Key Features:

#CP32xx #HMI #Multi-Touch Panel PCs

What are the cooling clearance requirements for this panel PC?

It requires a minimum of 20 cm (7.9 inches) of free space around the aluminum housing for passive heat dissipation.

Can the touch screen be operated with industrial work gloves?

Yes, the projective capacitive multi-touch sensor is calibrated to register inputs through standard thin industrial automation gloves.

How does the processor selection affect TwinCAT 3 licensing?

Lower-tier Celeron configurations fall under TwinCAT 3 performance class 50, whereas upgraded Core i7 configurations require performance class 80 licenses.

Does this panel PC support RAID 1 configurations?

Yes, the system is designed with an on-board SATA RAID 1 controller to coordinate redundant 2.5-inch SSD or HDD configurations.
