Engineered for high-performance industrial control and visualization, the Beckhoff CP2719-0020 fanless multi-touch built-in Panel PC delivers dependable HMI functionality in demanding environments. This robust industrial computer features a integrated 19-inch display with a resolution of 1280 x 1024, housed in a durable aluminum casing with a premium glass front. Its high-durability construction and fanless cooling system make it ideal for control cabinet installations across modern manufacturing facilities.
The core design of the CP2719-0020 centers on an Intel Atom processor, allowing efficient handling of TwinCAT PLC, HMI, and motion control tasks. Multi-finger touch capability provides intuitive user interaction, while dual CFast storage slots allow for secure, vibration-resistant operating system and data storage. Installation is simplified through integrated pull-out clamping levers, facilitating fast mounting without the risk of loose mechanical parts.
| Manufacturer | BECKHOFF |
| Part Number / Model | CP2719-0020 |
| Device Type | Fanless Multi-Touch Built-In Panel PC |
| Display Size | 19-inch |
| Resolution | 1280 x 1024 |
| Processor | Intel Atom x5-E3930 (1.3 GHz, 2 cores) or Intel Atom x5-E3940 (1.6 GHz, 4 cores) |
| Memory | 4 GB DDR4 RAM (expandable up to 8 GB ex factory) |
| Storage Slots | 2 x CFast slots (supports 40 GB to 320 GB CFast) |
| Onboard Ethernet | 2 x 100/1000BASE-T ports (option for 1 additional) |
| Interfaces | 2 x USB 3.0, 2 x USB 2.0, 1 x DVI, 1 x USB (front side) |
| PCIe Expansion | 1 x PCIe module slot (optional) |
| Housing Material | Aluminum housing with glass front |
| Power Supply | 24 V DC (optional UPS integration) |
| Protection Rating | IP65 (front), IP20 (rear) |
| Operating Temperature | 0 to 55 degC |
| Shipping Weight | 5.0 kg |
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: CP2719-0020
Country of origin:Germany
Product Type: Built-in Panel PCs
Payment: T/T, Western Union
Weight: 5000g
Shipping port: Xiamen
Warranty: 12 months
Engineered for high-performance industrial control and visualization, the Beckhoff CP2719-0020 fanless multi-touch built-in Panel PC delivers dependable HMI functionality in demanding environments. This robust industrial computer features a integrated 19-inch display with a resolution of 1280 x 1024, housed in a durable aluminum casing with a premium glass front. Its high-durability construction and fanless cooling system make it ideal for control cabinet installations across modern manufacturing facilities.
The core design of the CP2719-0020 centers on an Intel Atom processor, allowing efficient handling of TwinCAT PLC, HMI, and motion control tasks. Multi-finger touch capability provides intuitive user interaction, while dual CFast storage slots allow for secure, vibration-resistant operating system and data storage. Installation is simplified through integrated pull-out clamping levers, facilitating fast mounting without the risk of loose mechanical parts.
| Manufacturer | BECKHOFF |
| Part Number / Model | CP2719-0020 |
| Device Type | Fanless Multi-Touch Built-In Panel PC |
| Display Size | 19-inch |
| Resolution | 1280 x 1024 |
| Processor | Intel Atom x5-E3930 (1.3 GHz, 2 cores) or Intel Atom x5-E3940 (1.6 GHz, 4 cores) |
| Memory | 4 GB DDR4 RAM (expandable up to 8 GB ex factory) |
| Storage Slots | 2 x CFast slots (supports 40 GB to 320 GB CFast) |
| Onboard Ethernet | 2 x 100/1000BASE-T ports (option for 1 additional) |
| Interfaces | 2 x USB 3.0, 2 x USB 2.0, 1 x DVI, 1 x USB (front side) |
| PCIe Expansion | 1 x PCIe module slot (optional) |
| Housing Material | Aluminum housing with glass front |
| Power Supply | 24 V DC (optional UPS integration) |
| Protection Rating | IP65 (front), IP20 (rear) |
| Operating Temperature | 0 to 55 degC |
| Shipping Weight | 5.0 kg |
