BECKHOFF CP3724-0010 CP37xx Multi-touch Panel PC

Description

Engineered for robust control terminal applications directly at the machine, the Beckhoff CP3724-0010 is a high-performance, fully enclosed IP65 industrial multi-touch Panel PC. This unit integrates a brilliant 24-inch widescreen display with capacitive multi-finger touch technology, enabling modern, intuitive operator interfaces in demanding industrial settings.

The system is housed in a rugged aluminum enclosure specifically designed for mounting arm installation. It features passive cooling via integrated heat sink structures supplemented by an internal fan for even heat distribution across all housing walls. Powered by efficient Intel Atom processors, the CP3724-0010 delivers reliable processing performance for visualization, HMI, and control tasks while operating fanless externally. Dual CFast slots provide dependable solid-state storage, and integrated Gigabit Ethernet interfaces ensure seamless connectivity to control networks and EtherCAT-based field devices.

Features

• 24-Inch Multi-Touch Display: High-resolution 1920 x 1080 widescreen display with multi-finger capacitive touch technology.
• All-Around IP65 Protection: Fully enclosed aluminum housing designed to withstand dust, moisture, and washdown environments.
• Flexible Mounting: Integrates with rotatable and tiltable mounting arm systems (compatible with Rittal and Rolec 48 mm tube standards) from the top or bottom.
• Efficient Thermal Design: External fanless operation utilizes a passive heat-sink design with an internal fan to eliminate hotspots.
• Industrial-Grade Storage: Dual CFast slots facilitate separate operating system storage and user data logging.

Applications

• Automotive manufacturing line control and visualization.
• Food, beverage, and packaging machinery HMI.
• Machine tool control stations.
• Process monitoring in water treatment and energy distribution.

Technical Specifications

Installation Guidelines

• Thermal Management: Maintain a minimum of 20 cm (7.9 inches) of free space around the Panel PC housing to allow unobstructed passive heat dissipation.
• Mounting: Securely attach the device to a compatible 48 mm diameter tube mounting arm system. Verify the load-bearing rating of the selected arm prior to assembly.
• Ingress Protection: To maintain the IP65 rating, ensure that all cable entries, gland plates, and unused IP65 connectors are completely sealed and tightly fastened.
• Grounding: Connect the functional ground terminal on the chassis directly to the central machine ground potential using a low-impedance conductor.
