BECKHOFF CP6203-0021-0070 Economy Built-in Panel PC

Only 10 item(s) left in stock

Manufacturer: BECKHOFF
Product No.: CP6203-0021-0070
Country of origin:Germany
Product Type: Industrial Panel PCs
Payment: T/T, Western Union
Weight: 5000g
Shipping port: Xiamen
Warranty: 12 months

Description

Integrating direct PLC control and high-performance visualization, the Beckhoff CP6203-0021-0070 functions as a space-saving, fanless industrial panel PC designed for control cabinet installation. This built-in industrial PC combines a high-performance motherboard, flexible storage configurations, and integrated interface ports with a robust housing construction to support TwinCAT automation software directly at the machine level. Built with a front-side IP65 ingress protection design, it interfaces seamlessly with EtherCAT-based control systems and standard industrial networks to provide direct human-machine interface (HMI) processing in demanding environments.

Features

Fanless industrial design with integrated 3.5-inch motherboard architecture.
Rugged housing featuring an aluminum front and sheet-steel rear cover for electromagnetic shielding and physical durability.
Integrated pull-out clamping levers for fast, tool-free installation into control panels.
On-board SATA RAID 1 controller configuration options for data redundancy.
Dual 100/1000BASE-T Ethernet ports on-board for simultaneous fieldbus communication and corporate network routing.
Dedicated storage slots for both 2.5-inch drives and CFast cards.
Direct runtime integration support for TwinCAT 2 and TwinCAT 3 industrial control software.

Applications

Power generation and distribution control panels.
Automotive assembly lines and robotic manufacturing cells.
Oil and gas supervisory control and data acquisition stations.
Water and wastewater treatment plant control consoles.
General CNC machine tool control and system visualization.

Technical Specifications

Manufacturer	BECKHOFF
Part Number / Model	CP6203-0021-0070
Device Type	Economy built-in Panel PC
Housing Material	Aluminum front, sheet-steel rear cover
Storage Slots	1 x 2.5-inch HDD/SSD slot, 1 x CFast slot
Mounting Method	Pull-out clamping levers for panel integration
Protection Rating	Front side IP65, rear side IP20
Operating Temperature	0 to 55 degC
Processor	Intel Celeron G3900TE 2.3 GHz, 2 cores (supports up to Intel Core i7 7700T 2.9 GHz)
Motherboard	3.5-inch motherboard for 6th/7th generation Intel Celeron, Pentium, Core i3/i5/i7
Memory	4 GB DDR4 RAM (expandable up to 32 GB ex factory)
Ethernet Interface	2 x 100/1000BASE-T on-board ports
RAID Controller	On-board SATA RAID 1 controller
Standard Interfaces	4 x USB 3.0, 1 x RS232, 1 x DVI
Power Input	24 V DC (UPS options available)
Shipping Weight	5 kg

Connections and Interfaces

Interface Type	Specification / Quantity
USB Ports	4 x USB 3.0 interfaces
Serial Port	1 x RS232 serial interface
Video Port	1 x DVI video connector
Ethernet Ports	2 x RJ45 ports (10/100/1000 Mbps)
Power Supply Connection	24 V DC terminal block

Installation Guidelines

Verify the cutout dimensions on the control cabinet panel match the unit profile before installation.
Insert the PC into the cutout and secure it from behind using the integrated pull-out clamping levers. Do not over-torque the securing elements.
Ensure the front gasket is seated evenly to maintain the IP65 seal against dust and liquid ingress.
Provide at least 50 mm of free ventilation space above and below the rear cover to allow natural convection cooling.
Connect the protective earth (PE) terminal on the rear chassis to the main ground busbar using a low-impedance conductor.

Key Features:

#Beckhoff CP62xx #Industrial Panel PCs

What is the standard mounting method for the CP6203-0021-0070?

The CP6203-0021-0070 features pull-out clamping levers on the sides, facilitating fast, tool-free installation directly into control cabinet panels.

What is the IP protection rating of this built-in Panel PC?

The front side of the unit is rated IP65 for dust and water protection, while the rear side is rated IP20.

Does this Beckhoff Panel PC require active fan cooling?

No, this economy built-in Panel PC series is designed as a fanless industrial PC, relying on natural convection for heat dissipation.

What expansion storage options are supported?

The Panel PC provides one dedicated slot for a 2.5-inch hard disk or solid-state drive (SSD), along with dedicated CFast card slots.
