Description
Designed to act as a central operator interface, the Beckhoff CP6502-0001-0080 combines reliable computing capabilities with a high-visibility visualization screen. This built-in Panel PC features a 15-inch display and is designed for direct installation into control cabinets and command panels, ensuring optimal operational ergonomics on the plant floor.
Key Features
-
High-Resolution Display: Built-in 15-inch screen offering a crisp 1024 x 768 pixel resolution for process monitoring.
-
Robust Industrial Front: IP65 protection rating on the front panel shields the unit against dust, moisture, and spray.
-
Secure Mounting System: Pull-out clamping levers facilitate fast, stable installation into console panels without loose components.
-
Dual Gigabit Connectivity: Equipped with two onboard 100/1000BASE-T Ethernet interfaces for independent network routing.
Applications
- Machine tool control and direct HMI plant integration.
- Automotive assembly line tracking and supervisory control.
- Process automation visualization in manufacturing facilities.
Technical Specifications
| Parameter |
Specification |
| Manufacturer |
Beckhoff |
| Model / Article Number |
CP6502-0001-0080 |
| Device Type |
Built-in Panel PC |
| Display Size |
15-inch |
| Resolution |
1024 x 768 pixels |
| Front Protection Rating |
IP65 |
| Rear Protection Rating |
IP20 |
| Operating Temperature |
0 to 55 degC |
| Ethernet Ports |
2 x 100/1000BASE-T (onboard) |
| Mounting Method |
Pull-out clamping levers |
| Shipping Weight (Calculated) |
9.0 kg |
Installation Guidelines
CRITICAL WARNING
Isolate and lock out all main power sources before starting the installation. Verify that no residual voltages are present in nearby connections to avoid electric shock or device damage during cabinet mounting.
1
Verify that the cutout in the control cabinet door matches the physical dimensions required for a 15-inch panel insert.
2
Insert the Panel PC into the front cutout, ensuring the integrated gasket is properly aligned to maintain IP65 ingress protection.
3
Secure the device from the rear using the built-in pull-out clamping levers. Tighten securely to ensure a robust seal without warping the cabinet door.
4
Connect ground lines to the protective earth terminal and plug in the power supply and interface cables.
