BECKHOFF CP6703-0000-0060 Built-in Panel PC

Description

The BECKHOFF CP6703-0000-0060 is an economy built-in Panel PC designed for industrial control cabinets and operator stations. Featuring a 19-inch display with a resolution of 1280 x 1024, this device combines computing hardware and visualization in a single unit suitable for machine operation and process monitoring tasks.

Constructed with an aluminum front and a sheet-steel rear cover, the Panel PC is engineered for panel mounting using pull-out clamping levers that allow for fast installation without loose parts. It functions as a compact computing node within industrial automation architectures, providing local operation, visualization, and communication interfaces for machine-level control applications.

Features

• 19-inch display with 1280 x 1024 resolution for clear visualization
• Built-in Panel PC architecture combining display, processing, and storage
• Robust aluminum front housing with protection rating IP65 on the front side
• Sheet-steel rear cover with protection rating IP20
• Pull-out clamping levers for toolless and fast panel installation
• Integrated Ethernet interfaces for network communication
• On-board USB and DVI interfaces for peripheral connection

Applications

• Machine operator panels and visualization terminals
• Industrial automation and control system interfaces
• Process monitoring and data logging workstations
• HMI applications in manufacturing and factory automation environments

Technical Specifications

General

Display and Operation

Processing and Memory

Interfaces and Communication

Storage and Power Supply

Environmental and Mechanical

Installation Guidelines

1. Verify that the exact model CP6703-0000-0060 matches your system requirements and cabinet cutout specifications before starting installation.
2. Ensure all power supplies to the control cabinet and the mounting location are switched off and locked out before handling electrical connections.
3. Inspect the unit and panel cutout for damage, debris, or incorrect dimensions to maintain the specified sealing integrity.
4. Insert the Panel PC into the control cabinet cutout from the front, ensuring the front gasket seats evenly against the mounting surface to achieve the IP65 protection rating.
5. Engage the pull-out clamping levers to secure the unit firmly into the panel without using loose parts.
6. Connect the 24 V DC UPS power supply and grounding conductors securely to the designated terminals.
7. Connect network cables, USB devices, and DVI peripherals to their respective ports as required by the system architecture.
8. Restore power and perform initial system commissioning checks.
