Description

Designed for compact control and visualization tasks directly on the machine, the CP6622-0000-0020 built-in Panel PC combines an industrial-grade display with a high-performance ARM processor. This robust hardware solution is engineered to operate directly on-site in demanding industrial environments, functioning as both a reliable controller and a Human-Machine Interface (HMI).

Housed in a sturdy aluminum front with a sheet-steel rear cover, the unit provides IP65 protection on the front side, making it highly resistant to dust and moisture ingress. At the core of the device is an ARM Cortex-A8 processor operating at 1 GHz, backed by 1 GB of DDR3 RAM and non-volatile 128 kByte NOVRAM memory to prevent data loss in the event of power disruptions. Industrial communication is supported natively through on-board Ethernet and EtherCAT interfaces, allowing seamless integration with TwinCAT control systems.

Features

• High-Contrast Display: 15-inch display screen with a resolution of 1024 x 768 pixels for clear visualization.
• Efficient Processing Power: Low-power ARM Cortex-A8 1 GHz processor on a 3.5-inch motherboard.
• Reliable Storage & Persistence: 512 MB microSD flash card storage with 128 kByte NOVRAM for persistent retain data.
• Industrial Interfaces: Equipped with dual USB 2.0 ports and one RS232 serial connection.
• Integrated Connectivity: Features one 10/100BASE-T Ethernet port and one EtherCAT port on-board.
• Toolless Mechanical Installation: Utilizes pull-out clamping levers for fast, secure panel integration without loose mounting hardware.

Applications

• Machine-level visualization and operation (HMI).
• Decentralized control architectures via EtherCAT.
• Factory automation and production line monitoring.
• Packaging, material handling, and process control systems.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mounting: Insert the device into the prepared control cabinet cutout. Secure using the integrated pull-out clamping levers. Tighten the levers evenly to compress the front-plate seal and achieve the IP65 rating.
• Power Supply Connection: Use a low-noise, regulated 24 V DC power supply. Ensure appropriate grounding principles are followed to prevent electromagnetic interference (EMI).
• Ventilation: Ensure a clearance space of at least 50 mm above and below the rear housing cover to permit sufficient convective air circulation. Do not operate the device in sealed spaces with ambient temperatures exceeding 55 degC.
