Description

The BECKHOFF CP7203-0021-0060 is a high-performance Economy Panel PC designed for mounting arm installation, combining an industrial-grade operator control panel with an integrated PC engine. Featuring a 19-inch TFT display with a sharp 1280 x 1024 resolution, this unit is engineered to deliver robust visualization and processing power directly to the machine level without requiring a separate control cabinet.

Constructed with a rugged IP65-rated aluminum housing, the device is optimized to withstand demanding manufacturing environments. Thermal management is handled efficiently through a passive heat sink structure between the Control Panel and the add-on PC, supported by an internal circulation fan that ensures even heat distribution across all housing walls. This allows for reliable operation in temperatures ranging from 0 to 45 degC.

The system features a dedicated, protected wiring area designed for up to six IP65 connectors, allowing secure, clean routing of Ethernet and power cabling. Supported by a rotatable mounting arm adapter compatible with standard 48 mm tube systems, this Panel PC provides flexible positioning and optimal ergonomics for operators on the factory floor.

Features

• 19-inch high-resolution TFT display (1280 x 1024 pixels) for clear operator visualization.
• Robust, fully sealed IP65-rated aluminum housing for reliable dust and moisture protection.
• Rotatable mounting arm adapter compatible with Rittal and Rolec 48 mm tube systems.
• Efficient passive cooling design utilizing a specialized heat sink structure and an internal air distribution fan.
• Integrated 3.5-inch industrial motherboard supporting high-performance Intel processing architectures.
• Protected wiring connection chamber for up to six IP65 connectors.
• Built-in 24 V DC power supply designed for industrial grid stability.

Applications

• Machine-level human-machine interface (HMI) and supervisory control.
• Automated manufacturing lines requiring mounting-arm-mounted control panels.
• Material handling, logistics, and assembly systems.
• Industrial visualization in dusty, wet, or washdown-adjacent production zones.

Technical Specifications

Installation Guidelines

1. Power Isolation: Ensure all incoming 24 V DC power sources are completely de-energized before mounting, configuring, or connecting the device.
2. Mounting: Mount the PC securely to a compatible 48 mm tube mounting arm system. Verify that the rotatable adapter is locked and adjusted according to the structural requirements of your mounting setup.
3. Air Circulation: Maintain a minimum of 20 cm (7.9 inches) of free space around the rear heat sink structure of the PC to allow sufficient convective cooling.
4. Cabling: Route all connection cables safely through the mounting arm tube and into the designated IP65 wiring area.
5. Environmental Sealing: Securely tighten the access panel of the wiring area and ensure any unused connection ports are plugged with IP65-rated protective caps to preserve the environmental seal.

Replacement Recommendations

• Backup Configuration: Before replacing an active CP7203 unit, perform a full system backup of the operating system, storage drive, TwinCAT configurations, and active licenses.
• Match Specifications: Ensure that the replacement PC model matches the processing power, RAM, and terminal configuration of the existing unit to prevent runtime and software mismatch errors.
