BECKHOFF CPX3919-0010 CPX Series Multi-touch Control Panel

Description

Integrating robust visualization and single-cable connection architecture for hazardous industrial environments, the Beckhoff CPX3919-0010 operates as a high-performance operator interface within Zone 2 and Zone 22 classified areas. This CPX-series control panel combines a widescreen 21.5-inch display with capacitive multi-touch capabilities, housed in a durable, corrosion-resistant aluminum enclosure with a laminated glass front.

The integration of CP-Link 4 (One Cable Display Link) technology enables the transmission of video signals (DVI), USB 2.0 data (up to 100 Mbit/s), and power over distances up to 100 meters using a single Cat.6A network cable. Depending on the upstream transmitter module, power can be delivered directly through the CP-Link 4 connection or via a separate 24 V DC power source through dedicated IP65-rated M12 round connectors.

Features

• Widescreen 21.5-inch display with a resolution of 1920 x 1080 pixels.
• Capacitive multi-finger touch sensor screen behind a protective laminated glass front.
• Robust IP65 ingress protection across the entire enclosure, suitable for demanding environments.
• Integrated CP-Link 4 technology for clean, single-cable installations up to 100 meters.
• Explosion-protected aluminum housing certified for international hazardous zone standards.
• Rigid mechanical mounting interface using 4 x M6 threaded holes on a 100 x 100 mm pitch.

Applications

• Oil, gas, and petrochemical refining systems.
• Pharmaceutical processing facilities and cleanroom applications.
• Chemical processing and hazardous material processing areas.
• Milling, grain handling, and dust-prone industrial environments.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Ensure the mechanical mounting arm adapter is firmly secured to the 4 x M6 threaded holes using the standard 100 x 100 mm layout.
• Utilize high-quality, shielded Cat.6A cables to guarantee reliable CP-Link 4 transmission and power-over-cable performance up to 100 meters.
• Verify that all M12 connectors are fully tightened to maintain the device's IP65 sealing and safety ratings in hazardous atmospheres.
• Provide adequate structural grounding in accordance with local safety standards for explosive environments (Zone 2/22).

Compliance and Certifications

• CE / UL: Compliant
• ATEX Zone 2/22: II 3 G Ex nA IIC T5 Gc, II 3 D Ex tc IIIC T100 degC Dc
• IECEx Zone 2/22: Ex nA IIC T5 Gc, Ex tc IIIC T100 degC Dc
• cFMus Class Division 2: Class I, II, III, Division 2, Groups A, B, C, D, F, and G
• cFMus Zone 2/22: Class I, Zone 2, AEx ec IIC T5 Gc; Zone 22, AEx tc IIIB T100 degC Dc
