BECKHOFF EL3062-0030 EtherCAT Terminal 2-channel Analog Input Terminal

SKU EL3062-0030

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: EL3062-0030
  • Origin Germany
  • Product Type: Analog Input Terminals
  • Payment: T/T, Western Union
  • Weight: 1.5 kg
  • Dimensions: 10 cm x 1.5 cm x 7 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Analog Input Terminals EtherCAT
Quantity
Call sales Contact

Product Description

Description

Processing standard single-ended analog signals in industrial automation systems is efficiently handled by the EL3062-0030. This robust analog input terminal operates within the 0 V to +10 V voltage range, digitizing incoming signals with a high-performance 12-bit resolution for transmission to the master control system. Engineered for seamless integration with the Beckhoff EtherCAT Terminal system, it combines high-speed communication via the internal E-bus with galvanic safety features. Compact and highly reliable, it is ideal for standard control applications requiring fast, noise-immune signal acquisition.

Features

  • Dual single-ended analog inputs configured for 0 V to +10 V signal ranges.
  • Digitization resolution of 12 bits with a 16-bit representation format.
  • Typical conversion time of 0.625 ms using the default 50 Hz internal filter.
  • Galvanic electrical isolation rated at 500 V between the E-bus and the field circuit.
  • Integrated 1 kHz input limit filter for high-frequency noise suppression.
  • Excellent electromagnetic compatibility complying with industrial emission and immunity standards.

Applications

This 2-channel analog input terminal is widely implemented across heavy industrial and manufacturing environments, including:

  • Machine control and process automation.
  • Continuous monitoring of industrial sensors and transmitters.
  • Factory automation lines requiring reliable 0-10 V analog data acquisition.
  • Test bench and laboratory instrumentation setups.

Technical Specifications

Manufacturer BECKHOFF
Part Number / Model EL3062-0030
Product Type 2-channel Analog Input Terminal
Number of Inputs 2 (single-ended)
Signal Voltage Range 0 V to +10 V
Internal Resistance > 130 kOhm
Resolution 12 bit (16 bit presentation)
Conversion Time Typical 0.625 ms (default 50 Hz filter setting)
Input Filter Limit Frequency 1 kHz
Measuring Error (Full Range) < ± 0.30% (at 0 degC to +55 degC, relative to full scale); < ± 0.5% (extended temperature range)
Current Consumption via E-Bus Typical 130 mA
Electrical Isolation 500 V (E-bus / field voltage)
Dielectric Strength Max. 30 V
Permissible Relative Humidity 95%, non-condensing
EMC Immunity / Emission Conforms to EN 61000-6-2 / EN 61000-6-4
Protection Class IP20
Dimensions (H x W x D) Approx. 10 cm x 1.5 cm x 7 cm
Shipping Weight 1.5 kg

Installation Guidelines

For safe and optimal performance of the terminal block, adhere to the following installation standards:

  • DIN Rail Mounting: Snap the terminal securely onto a standard 35 mm DIN rail (EN 60715). Ensure the locking mechanism engages properly with adjacent terminals.
  • Shielding and Grounding: To minimize high-frequency electromagnetic interference, use shielded signal cables and connect the shield directly to the mounting rail or grounding terminal.
  • Environmental Protection: Ensure the installation enclosure provides an IP54 or higher rating if operating in harsh, dust-heavy, or wet industrial environments, as the module itself is rated IP20.
