Beckhoff IP2020-B310 Fieldbus Box Output Module

SKU IP2020-B310

In stock

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: IP2020-B310
Country of origin:Germany
Product Type: Fieldbus Modules
Payment: T/T, Western Union
Weight: 1000g
Dimensions: 30 mm x 175 mm x 26.5 mm
Shipping port: Xiamen
Warranty: 12 months

Description

Decentralized industrial environments demand robust field-level hardware, which the Beckhoff IP2020-B310 output module provides through direct integration. This high-reliability fieldbus box features 8 digital outputs designed for controlling actuators, solenoid valves, and indicator lamps directly in the field without requiring additional protective enclosures. Utilizing a high-speed PROFIBUS DP interface, the module automatically detects baud rates up to 12 Mbaud, allowing seamless installation into existing high-speed industrial networks.

The unit features 8 mm snap-type connectors for convenient I/O wiring, reducing installation and maintenance times. Engineered for durability, the PA6 polyamide housing provides superior mechanical and environmental resilience, making it suitable for demanding conditions in modern automation architectures.

Features

Features 8 digital outputs with 8 mm snap-type connections for fast installation.
Supports automated PROFIBUS DP baud rate detection up to 12 Mbaud.
Offers 2 A of load current per channel, with individual short-circuit protection and a maximum total sum current of 4 A.
Equipped with standardized M12 5-pin, B-coded sockets for robust fieldbus communication.
Provides convenient loop-through power supply via 4-pin M8 male and female sockets.
Housed in a rugged PA6 polyamide enclosure with a variable mounting position and high protection rating.

Applications

Automated assembly lines and conveyors
Pneumatic valve terminal control systems
Packaging machinery control
Automated material handling systems
Process control field distribution

Technical Specifications

ManufacturerModel / Part NumberProduct SeriesNumber of OutputsOutput Connector TypeBus InterfaceData Transfer RatesNominal Output VoltageMax. Output CurrentPower Supply ConnectionBox Supply CurrentHousing MaterialProtection RatingOperating TemperatureStorage TemperatureDimensions (W x H x D)Weight

Beckhoff Automation

IP2020-B310

Fieldbus Box

8 digital outputs

8 mm snap type

1 x M12 socket, 5-pin, B-coded

Automatic detection up to 12 Mbaud

24 V DC (-15% / +20%)

2 A per channel (individually short-circuit proof, total sum 4 A)

Feed: 1 x M8 male socket (4-pin); Downstream: 1 x M8 female socket (4-pin)

85 mA + current consumption of sensors (max. 0.5 A)

PA6 (Polyamide)

IP65/66/67 (conforms to EN 60529)

0 to 55 degC

-25 to 85 degC

30 mm x 175 mm x 26.5 mm

1.0 kg (Shipping weight)

Connections and Interfaces

Interface Type	Connector Style	Function
Fieldbus Interface	M12 Socket, 5-pin, B-coded	PROFIBUS DP high-speed network communication
Power Feed	M8 Male, 4-pin	24 V DC Control and auxiliary power supply input
Power Downstream	M8 Female, 4-pin	Power loop-through to adjacent Fieldbus Box modules
Digital Outputs	8 mm Snap Connectors (8 ports)	Actuator and load signal distribution

Installation Guidelines

Mount the module securely using the two integrated 3.5 mm diameter fixing holes intended for M3 screws.
Ensure that the environmental temperature remains between 0 and 55 degC during continuous operation.
To achieve the specified IP67 protection rating, all unused M8, M12, and snap-type ports must be sealed with appropriate protective caps.
Ensure correct routing of shielded copper communication cables (2 x 0.25 mm square recommended) away from high-power supply cables to minimize electromagnetic interference.

Compliance and Certifications

CE
UL
Conforms to EN 60068-2-6 (vibration resistance) and EN 60068-2-27 (shock resistance)
Conforms to EN 61000-6-2 (EMC immunity) and EN 61000-6-4 (EMC emission)

FAQ

What fieldbus protocol does the Beckhoff IP2020-B310 support?

The IP2020-B310 module supports the PROFIBUS DP protocol with automatic baud rate detection up to 12 Mbaud, connected via a B-coded, 5-pin M12 interface.

What is the maximum current rating for the digital outputs?

Each digital output can supply up to 2 A of current. However, the total sum current across all outputs must not exceed 4 A. Each channel is individually short-circuit proof.

How is the module powered and can the power be looped to other modules?

The module is powered via a 4-pin M8 male socket. An adjacent 4-pin M8 female socket allows loop-through of the 24 V DC control voltage to neighboring Fieldbus Box modules.

What protection rating does the IP2020-B310 have?

The module has an IP65, IP66, and IP67 protection rating (conforming to EN 60529), provided all unused connector sockets are properly sealed.
