BECKHOFF IP2022-B200 Lightbus Fieldbus Box

Description

The BECKHOFF IP2022-B200 is a decentralized Fieldbus Box designed for robust industrial automation environments. By shifting I/O operations directly onto the machinery, it helps reduce control cabinet space and cabling complexity. This module features 8 digital output channels capable of driving standard 24 V DC actuators with high load demands.

Equipped with a Lightbus interface, the BECKHOFF IP2022-B200 ensures fast, noise-immune communication via optical fiber rings. The physical housing provides an IP67 protection rating, making it suitable for wet, dusty, or high-vibration conditions. Connections are established using standard M12 screw connectors for reliable operation under physical stress.

Features

• 8 digital output channels for decentralized signal control
• Integrated Lightbus fiber-optic fieldbus interface
• Nominal output voltage of 24 V DC
• Maximum output current of 2 A per channel
• Secure M12 screw connector design
• IP67-rated housing for cabinet-free mounting

Applications

• Decentralized machine control and automation networks
• Material handling systems and conveyor lines
• Pneumatic valve terminal control
• Industrial assembly and packaging machinery

Technical Specifications

Installation Guidelines

1. Verify the BECKHOFF IP2022-B200 part number and physical condition before installation.
2. De-energize the entire system, including fieldbus supply and auxiliary power, before mounting or wiring the module.
3. Mount the unit securely to a flat machine surface using the integrated mounting holes.
4. Connect the Lightbus optical fibers, ensuring correct ring-topology routing and minimum bend radii are respected.
5. Attach M12 actuator cables, tightening the connectors to the recommended torque to preserve the IP67 seal.
6. Reapply power and inspect diagnostic indicators during initial startup.

Replacement Recommendations

When replacing an existing BECKHOFF IP2022-B200, ensure the replacement module's hardware revision matches the system configuration. Document all existing M12 actuator and optical fiber connections before removal. Clean any debris from the mounting area and ensure the sealing rings on M12 plugs are intact before reattaching them to the replacement unit.
