BECKHOFF KM3701-0340 Differential Pressure Input Terminal

SKU KM3701-0340

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: BECKHOFF

  • Product No.: KM3701-0340

  • Country of origin:Germany

  • Product Type: Bus Terminal module

  • Payment: T/T, Western Union

  • Weight: 3000g

  • Shipping port: Xiamen

  • Warranty: 12 months

The KM3701-0340 is a specialized 1-channel analog input terminal designed for precision differential pressure measurement. Manufactured by BECKHOFF, this module is optimized for applications involving non-aggressive gases, offering a measuring range of -100 to +100 hPa (-100 to +100 mbar). Featuring a resolution of 0.1 hPa per digit and a fast typical measuring speed of 5 ms, the KM3701-0340 is an ideal solution for accurate pressure monitoring and control tasks in ventilation, climate control, and industrial process automation.

Features

  • 1-channel differential pressure measurement
  • Measuring range: -100 to +100 hPa (-100 to +100 mbar)
  • High resolution: 0.1 hPa per digit
  • Fast measuring speed: 5 ms typical
  • Suitable for non-aggressive gases
  • Robust design with overload protection: 500 hPa differential / 5000 hPa to ambient
  • Compact terminal module design for K-bus integration

Applications

  • HVAC system pressure monitoring
  • Filter performance tracking
  • Airflow and differential pressure measurement in industrial processes
  • Cleanroom pressure control

Technical Specifications

Category Specification
Manufacturer BECKHOFF
Model KM3701-0340
Measuring Range -100 to +100 hPa
Max. Overload 500 hPa differential, 5000 hPa to ambient
Resolution 0.1 hPa per digit
Measuring Error 3 % (relative to full scale)
Measuring Speed 5 ms typical
Current Consumption (K-bus) typ. 15 mA
Operating Temperature 0 to +55 degC
Storage Temperature -25 to +85 degC
Protection Rating IP20

Installation Guidelines

  • Ensure the module is installed in an environment free of aggressive or corrosive gases, as it is only suitable for non-aggressive gas media.
  • Mount the terminal on a standard 35 mm DIN rail in a position that minimizes external vibration.
  • Use appropriate pressure tubing compatible with the terminal's pressure connection ports to ensure a leak-free installation.
  • Maintain ambient conditions between 0 and +55 degC for optimal measurement accuracy.
  • Adhere to EMC standards EN 61000-6-2/EN 61000-6-4 by ensuring correct grounding of the mounting rail and cabling practices.

Compliance and Certifications

  • CE
  • UL

FAQ

What is the measuring range of the KM3701-0340?
The measuring range is -100 to +100 hPa (-100 to +100 mbar).

What kind of media can be measured with this terminal?
This terminal is designed for use with non-aggressive gases only.

How fast is the measuring speed?
The typical measuring speed is 5 ms.

What is the maximum pressure overload for this module?
The maximum differential overload is 500 hPa, and the maximum pressure allowed to ambient is 5000 hPa (5 bar).
