Description
Position and velocity evaluation within automated systems is streamlined using the Beckhoff KS5111 Bus Terminal. This module serves as a physical interface for the direct connection of 24 V DC incremental encoders conforming to EN 61131-2 Type 1 standards. By processing quadrature signals from industrial encoders, this terminal integrates high-speed mechanical motion feedback directly into the K-bus process image of your PLC or DCS architecture.
The unit features a 16-bit binary counter that can be read, set, or enabled via control bytes. A built-in zero-pulse latch allows the 16-bit register to lock on the zero-pulse (C track) signal, enabling highly repeatable homing sequences and precise registration-mark detection. Utilizing the pluggable connection level characteristic of the KS-series, the module facilitates swift field replacement without requiring the disconnection of individual terminal wires, keeping system downtime to a minimum.
Features
- Single-channel incremental encoder interface designed for 24 V DC sensor signals.
- Integrated quadrature decoder utilizing 4-fold evaluation for enhanced position resolution.
- High-speed 16-bit binary counter alongside an independent 16-bit zero-pulse latch register.
- Configurable operational commands for reading, setting, and enabling counter registers.
- Pluggable connection design (KS series) to allow fast wiring service and module swaps.
- Process image integration mapping 2 x 16-bit data and 2 x 8-bit control/status blocks.
Applications
- Real-time position tracking in material handling and conveyor installations.
- Speed and orientation feedback for packaging and labeling equipment.
- Homing sequences and mechanical reference positioning in CNC axes.
- Electronic gearing and angle measurement in printing processes.
Technical Specifications
Category
Technical Parameter
Value / Specification
| System Identification |
Manufacturer |
Beckhoff |
| Part Number / Model |
KS5111 |
| Module Type |
Bus Terminal (K-bus) |
| Wiring Level Design |
Pluggable connection level |
| Electrical Interface |
Number of Channels |
1 incremental encoder channel |
| Encoder Connection Signals |
A, B, C, 24 V DC |
| Input Specification |
EN 61131-2, Type 1 |
| Signal Voltage Level |
"0": < 5 V DC, "1": > 15 V DC (typ. 5 mA) |
| Encoder Operating Voltage |
24 V DC (-15% / +20%) |
| Maximum Limit Frequency |
1,000,000 increments/s (with 4-fold evaluation) |
| Processing & Data |
Internal Counter |
16-bit binary |
| Quadrature Decoder Mode |
4-fold evaluation |
| Process Image Bit Width |
Input/Output: 2 x 16-bit data, 2 x 8-bit control/status |
| Power Requirements |
K-bus Current Consumption |
typ. 40 mA |
| Max. Power Contact Current Load |
10 A |
| Mechanical & Wiring |
Connection Technology |
Pluggable spring-clamp system |
| Conductor Cross-section (Solid/Stranded) |
0.08 to 1.5 mm² (AWG 28 to 16) |
| Conductor Cross-section (Flexible) |
0.14 to 1.5 mm² (AWG 26 to 16) |
| Wire Stripping Length |
9 to 10 mm |
| Mounting Method |
35 mm DIN rail (EN 60715) with interlocking mechanism |
| Environmental Specs |
Operating Temperature Range |
0 to 55 degC |
| Storage Temperature Range |
-25 to 85 degC |
| Relative Humidity Limits |
95%, non-condensing |
| Ingress Protection Rating |
IP20 |
| Vibration & Shock Standards |
Conforms to EN 60068-2-6 / EN 60068-2-27 |
| Physical Attributes |
Dimensions (W x H x D) |
12 mm x 100 mm x 68 mm |
| Net Weight |
0.06 kg |
| Housing Material |
Polycarbonate |
Connections and Interfaces
| Signal Designation |
Function Description |
| A |
Encoder channel A input (quadrature signal) |
| B |
Encoder channel B input (90 degree phase-shifted signal) |
| C |
Encoder channel C input (zero-pulse / index marker) |
| 24 V |
Encoder power supply feed output |
Installation Guidelines
-
Mounting: Mount the bus terminal horizontally or vertically on standard 35 mm DIN rail. Secure the double slot and key connection with adjacent terminals to form a robust K-bus block.
-
Wiring Maintenance: Use a flat-blade screwdriver to actuate the spring-clamp terminals on the pluggable terminal block. Strip insulation back to exactly 9-10 mm for optimum clamping force and electrical contact.
-
Shielding & Grounding: Ensure encoder cables are shielded properly. Terminate the shield close to the entry point of the control panel to minimize electromagnetic interference on high-frequency signals.
Compliance and Certifications
- CE, UL
- ATEX: II 3 G Ex nA IIC T4 Gc
- EMC Immunity/Emission: Conforms to EN 61000-6-2 / EN 61000-6-4
