Bently Nevada 16710-14 Interconnect Cable

Description

16710-14 is a 14 ft (4.27 m) interconnect cable assembly designed for use with Bently Nevada 330400 and 330425 series acceleration transducers. This 3-conductor shielded 22 AWG (0.5 mm2) cable provides a reliable interface for casing vibration monitoring in industrial environments. It features a 3-socket plug connector on one end for attachment to the accelerometer, while the other end is terminated with lugs for installation into instrumentation housing or connection blocks.

This cable is built to maintain signal integrity for critical machinery applications. The shielded design minimizes electromagnetic interference, ensuring accurate transmission of vibration data from the sensor to the monitoring system. It is suitable for diverse industrial settings where continuous monitoring of gear mesh or bearing housing acceleration is required.

Features

• 14 ft (4.27 m) total cable length
• 3-conductor shielded 22 AWG (0.5 mm2) construction
• 3-socket plug connector (sensor end)
• Terminal lugs (instrumentation end)
• Compatible with 330400 and 330425 acceleration transducers

Applications

• Casing acceleration monitoring
• Gear mesh monitoring
• Bearing housing vibration measurement
• Rotating machinery protection in oil and gas, power generation, and petrochemical facilities

Ordering Information

Technical Specifications

Installation Guidelines

Standard installation for these cables involves routing through protective conduit to prevent physical damage and electrical interference. The cable should be kept away from high-voltage lines. Ensure the 3-socket plug is fully seated on the accelerometer to maintain environmental sealing. When terminating the lugs, ensure proper torque and connection to the monitoring system ground reference as specified in the accelerometer user guide.
