Bently Nevada 16925-35 Interconnect Cable

Description

16925-35 is a 3-conductor shielded 22 AWG (0.5 mm2) interconnect cable specifically configured with a 35 ft (10.7 m) length for use with 330400 and 330425 acceleration transducers. This cable features a 3-socket plug connector at the sensor end and bare terminal lugs at the instrumentation end, facilitating reliable signal transmission in critical machinery monitoring applications.

This cable assembly is engineered for use in industrial environments where casing acceleration measurements are required, such as gear mesh monitoring or bearing housing vibration analysis. The shielded construction helps maintain signal integrity by minimizing electromagnetic interference, while the 22 AWG conductors ensure appropriate electrical characteristics for the 330400/330425 accelerometer series. It is compatible with systems requiring the standard 3-pin MIL-C-5015 interface at the transducer connection point.

Features

• Length: 35 ft (10.7 m)
• Conductor: 3-conductor shielded 22 AWG (0.5 mm2)
• Connector (Sensor End): 3-socket plug
• Termination (Instrumentation End): Terminal lugs
• Compatibility: Bently Nevada 330400 and 330425 accelerometers

Applications

• Casing acceleration measurement
• Gear mesh monitoring
• Bearing housing vibration analysis
• General-purpose rotating machinery protection

Ordering Information

Technical Specifications
