Delta ASD-B2-0121-B+ECMA-C20401GS ASDA-B2 Series Servo Drive and Motor Kit

Description

The Delta ASD-B2-0121-B+ECMA-C20401GS is an integrated AC servo system engineered for high-precision motion control applications. This package pairs a 100W ASDA-B2 series servo drive with a matching ECMA series electrical commutation motor to deliver robust position, speed, and torque control. The ASD-B2-0121-B drive operates on versatile single-phase or three-phase 220V power inputs and interfaces directly with the 17-bit incremental encoder of the ECMA-C20401GS motor, ensuring high dynamic response, stable power delivery, and low-speed smoothness across various industrial automation tasks.

Features

• High-resolution 17-bit incremental encoder for precise position feedback
• Dual-input voltage compatibility supporting single-phase and three-phase 220V AC systems
• Standard drive layout with optimized thermal dissipation and compact housing
• High-density 40mm motor frame size providing efficient output power in constrained spaces

Applications

• Electronic component manufacturing and assembly
• Automated packaging machinery
• Small-scale CNC equipment and precision positioning tables
• Industrial robotics and pick-and-place automation systems

Technical Specifications

Installation Guidelines

• Ensure proper grounding of both the drive terminal and the motor housing to minimize electromagnetic interference.
• Maintain adequate ventilation space around the servo drive enclosure to enable effective heat dissipation.
• Use shielded twisted-pair cables for encoder feedback signal routing to prevent signal noise disruption.
• Confirm correct phase wiring prior to supplying 220V single-phase or three-phase AC input power.
