Manufacturer: EATON
Product No.: MTL9465-ET-S-SC
Country of origin:United Kingdom
Product Type: Intrinsically Safe Converter
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 700g
Dimensions: 75 × 55 × 116 mm
Shipping port: Xiamen
Warranty: 12 months
The MTL 9465-ET (MTL9465ET) is a rugged 10/100Mbps copper-to-fibre media converter designed for hazardous industrial environments. It extends Ethernet network distances up to 5 km while providing complete galvanic isolation and strong immunity to electrical noise, making it ideal for refineries, chemical plants, and mining operations.
This converter enables reliable data transmission from Zone 1 hazardous areas to safe-area control rooms, reducing signal degradation risks and preventing unexpected system downtime. Its transparent operation ensures full compatibility with existing 10/100Base-T infrastructure, making it a dependable bridge for modern IIoT automation networks.
The MTL 9465-ET supports 1300 nm optics and multiple fiber connection options. It is available with ST connectors for 62.5/125 µm multimode fiber, as well as SC connectors for both multimode and 9 µm single-mode fiber, allowing flexible deployment across different industrial network designs.
The copper interface uses a standard RJ45 connector for 10/100Base-T Ethernet. The fiber interface provides inherently safe optical output, enabling fiber routing through Zone 0 hazardous locations without introducing ignition risks.
The module can be powered by an external 12 VDC intrinsically safe supply or by PoEx (Power over IS Ethernet). The PoEx option allows power and data to be transmitted over a single Cat5e cable, simplifying wiring and reducing installation costs.
For extended distances, multiple converters can be cascaded with an MTL 9466 Ethernet switch. This configuration creates a high-speed repeater system that extends network coverage while also providing additional local connectivity ports.
| Feature | Specification |
|---|---|
| Model | MTL 9465-ET |
| Brand | Eaton |
| Origin | United Kingdom |
| Mounting | DIN Rail |
| Dimensions | 75 × 55 × 116 mm |
| Weight | 700 g |
| Operating Temperature | -40°C to +70°C |
| Power Input | 12 VDC (10–15.4 V) |
| Power Consumption | 160 mA |
| Data Rate | 10/100 Mbps Auto-Negotiation |
| Copper Port | RJ45, 100 m max |
| Fiber Type | Multimode / Single-mode |
| Fiber Distance | 2 km @100 Mbps / 5 km @10 Mbps |
| Optical Wavelength | 1300 nm |
Fiber optics provide excellent immunity to EMI and electrical interference. The inherently safe optical signal also allows long-distance communication without the risk of electrical ignition in explosive environments.
Yes. The module is ATEX and IECEx certified for hazardous areas, and approvals cover both surface industry and mining applications.
Front panel LEDs indicate power status, copper and fiber link status, and transmit/receive activity. These indicators help engineers quickly identify link speed, connectivity, and network faults.
When using PoEx, do not connect external power to screw terminals 1-4. Power is delivered through the RJ45 connector on pins 4/5 (positive) and 7/8 (return).
For proper duplex communication, the top fiber port is TX and the bottom port is RX when using ST or SC connectors.
When installed in Zone 1 or Division 1 areas, the converter must be mounted inside a certified enclosure that meets ingress protection and safety requirements.
The MTL 9465-ET supports wide-temperature operation from −40°C to +70°C and delivers higher reliability than standard commercial media converters. Transparent IEEE 802.3 operation removes the need for software configuration while supporting 10Base-T, 100Base-TX, and 100Base-FX networks.
The ability to extend 10 Mbps links up to 5 km over multimode fiber provides a cost-effective solution for remote telemetry and legacy field device connectivity.
