GE Energy IS230PCAAH1B Mark VIe Core Analog Module

SKU IS230PCAAH1B

In stock

12-month warranty
Free returns within 30 days

Manufacturer: General Electric
Product No.: IS230PCAAH1B
Country of origin:United States
Product Type: Core Analog Module
Payment: T/T, Western Union
Weight: 1200g
Dimensions: 28.0 x 18.0 x 8.0 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The IS230PCAAH1B is a Core Analog I/O Module manufactured by GE Energy for the Mark VIe gas turbine control system. It processes the primary portion of analog input and output signals required for gas turbine operation. Internal hardware incorporates a BPPC processor board paired with two application I/O boards (BCAA and BCAB) and a TCAS terminal board. The hardware design accepts analog input/output signals, LVDT excitation outputs, and TTL pulse inputs with power. Signals intended for a single hardware module connect directly to the edge terminal blocks, while signals fanned to simplex or TMR configurations route through an optional TCAT terminal board.

Features

Integrated BPPC processor board, BCAA and BCAB application I/O boards, and TCAS terminal board
Edge-mounted 120 Euro-style box-type terminal blocks for field device wiring
Support for fanned seismic inputs, fanned 4-20 mA inputs, and fanned LVDT feedback via an optional TCAT terminal board
Interface connections including dual RJ-45 Ethernet ports and a 28 V dc power connector
Three front-facing LED status indicators

Applications

Gas turbine core analog signal processing
Speed and position feedback acquisition in Mark VIe control systems
Industrial turbine control I/O interfacing

Technical Specifications

Parameter	Specification
Manufacturer	GE Energy
Part Number	IS230PCAAH1B
Product Type	Core Analog Module
Series	Mark VIe
Primary Functional Revision	B-rated
Chassis Type	Vented Chassis Style
Thermocouple Types	E, J, K, T, S
Analog Function	Core Analog
Accepted Signals	Analog input and output signals, LVDT excitation outputs, TTL pulse inputs + power
Power Connector	28 V dc power connector
Network Interfaces	Dual RJ-45 Ethernet connectors
Field Terminal Blocks	120 Euro-style box-type terminal blocks
Visual Indicators	3 front-facing LEDs

Installation Guidelines

Ensure 28 V dc power is safely disconnected prior to mounting or wiring the unit.
Connect field wiring to the 120 Euro-style box-type terminal blocks located on the module edge.
Direct single-module signals directly to the local terminals; route fanned signals for simplex or TMR setups through the optional TCAT terminal board.
Connect network communication cables to the dual RJ-45 Ethernet ports.
Maintain adequate spacing around the vented chassis to ensure passive thermal cooling.

FAQ

What internal boards are included in the module assembly?

The device contains a BPPC processor board, two application I/O boards (BCAA and BCAB), and a TCAS terminal board.

Which thermocouple types does the module support?

The device supports thermocouple types E, J, K, T, and S.

What is the function of the optional TCAT board?

The optional TCAT board enables fanned signal routing for seismic inputs, analog 4-20 mA inputs, and LVDT feedback in simplex or TMR configurations.

What power connection does the module require?

The module requires a 28 V dc power connection.
