The General Electric IC693ACC301 is a long-life lithium backup battery specifically designed for the GE Fanuc Series 90-30 programmable logic controller (PLC) platform. This essential component is utilized to maintain the contents of the CMOS RAM memory in the CPU during power outages or when the main system power is turned off, ensuring that valuable application programs, configuration data, and register values are preserved.
The battery is easily accessed by removing the cover plate located at the bottom of the power supply faceplate. It comes securely mounted on a plastic clip attached to the inside of this cover and connects to the CPU through a dedicated cable equipped with a Berg female connector. Designed for maximum reliability and operational continuity, the IC693ACC301 can be safely replaced while power is applied to the PLC, minimizing costly system downtime.
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE Fanuc) |
| Catalog Number / SKU | IC693ACC301 |
| Product Type | RAM Memory Backup Battery |
| Compatible Platform | Series 90-30 PLC Systems |
| Cell Chemistry | Lithium |
| Nominal Voltage | 3 VDC |
| Connection Type | Cable with Berg Female Connector |
| Shelf Life | 5 Years at Room Temperature (25 degC) |
| Country of Origin | United States |
The IC693ACC301 features a two-wire cable terminated with a small Berg female connector. This connector plugs directly into one of two identical male connectors mounted on the Series 90-30 power supply printed circuit board. The connection path routes through the power supply baseplate connector and across the backplane board to the RAM circuits, ensuring continuous power delivery to the memory architecture.
To prevent the loss of RAM memory contents during battery replacement, ensure you follow proper handling procedures. The battery can be replaced with PLC power turned on, provided qualified personnel perform the task using insulated tools. Carefully insert a small screwdriver into the battery cover removal slot beneath the cover plate, rotate 45 degrees to release, unplug the old battery connector, swap the battery on the retaining clip, plug in the new unit, and snap the cover back into place. Always verify battery age using the four-digit date code before installation.
Global Express Shipping
Returns & Warranty
Manufacturer: General Electric
Product No.: IC693ACC301
Country of origin:United States
Product Type: PLC Batteries
Payment: T/T, Western Union
Weight: 50g
Dimensions: 7.0 x 4.0 x 2.5 cm
Shipping port: Xiamen
Warranty: 12 months
