Manufacturer: General Electric
Product No.: IC755CSS06RDA
Country of origin:United States
Product Type: Operator Interface Terminal
Payment: T/T, Western Union
Weight: 800g
Dimensions: 19.2 x 13.7 x 3.6 cm
Shipping port: Xiamen
Warranty: 12 months
The General Electric IC755CSS06RDA QuickPanel is a high-performance 6-inch operator interface terminal designed to serve as an all-in-one HMI, PLC process controller, machine gateway, and data historian device within industrial automation architectures. Built around a Freescale i.MX535 1GHz ARM Cortex-A8 processor node with dedicated 2D and 3D graphics acceleration, this operator interface delivers robust visualization and real-time control capabilities directly to machine-level environments.
Equipped with a vibrant 6-inch TFT LCD resistive touch display featuring a 320 x 240 pixel resolution, the unit runs on the Microsoft Windows Embedded Compact 7 operating system. It supports full HTML5 browser functionality, multimedia playback, and object-based programming environments across five standard IEC languages. The terminal integrates seamlessly into distributed control networks via onboard Ethernet and serial communication ports, reducing total system footprint and engineering overhead.
| Parameter | Specification |
|---|---|
| Brand | General Electric |
| Catalog Number / SKU | IC755CSS06RDA |
| Display Size & Type | 6-inch TFT LCD Resistive Touch Display |
| Display Resolution | 320 x 240 pixels |
| Processor | Freescale i.MX535 1GHz (ARM Cortex-A8) |
| System Memory | 512MB DDR2 SDRAM |
| Storage Memory | 256MB SLC NAND Flash, 512KB Battery Backed SRAM |
| Operating System | Microsoft Windows Embedded Compact 7 |
| Ethernet Interface | 1x 10/100BaseT (RJ-45) |
| Serial Interface | 1x RS-232 COM Port (5-Pin Connector) |
| USB Ports | 2x USB 2.0 (Type-A), 1x USB 2.0 (Mini Type-B) |
| Storage Expansion | 1x SD/SDHC Card Slot |
| Input Voltage | +24VDC plus or minus 20 percent (3-pin connector) |
| Power Consumption | 15W maximum |
| Operating Temperature | 0 to 55 degC (32 to 131 degF) |
| Enclosure Rating | IP65F (Front Panel, JEM 1030) |
| Certifications & Approvals | UL Listed US/CAN, CE, FCC Part 15 Class A, RoHS |
| Country of Origin | United States |
The unit features a 3-pin power supply connector supporting +24VDC input, an RJ-45 port for 10/100BaseT Ethernet connectivity, and a 5-pin terminal block for RS-232 serial communication. Additional peripheral connections include two USB 2.0 Type-A ports, a Mini USB port, an SD/SDHC memory card slot, and 3.5mm audio jacks for mono microphone input and stereo line output.
