General Electric IS220PRTDH1AD Mark VI Resistance Temperature Input Module

Description

The General Electric IS220PRTDH1AD is an 8-channel Resistance Temperature Device (RTD) input module engineered for the Mark VIe turbine control system series. This specialized RTD Input Module interfaces field-mounted resistive thermal sensors directly with the primary industrial control processor backbone. The IS220PRTDH1AD functions as a high-density standalone I/O pack operating its own internal integrated power supply network.

Digital data distribution is achieved through dual communication pathways using native side-mounted Ethernet ports, allowing deterministic real-time data streaming within high-availability control architectures. Built upon an exhaustive conformal PCB coating architecture, the IS220PRTDH1AD offers enhanced defense properties against trace oxidation and atmospheric particulate buildup across high-temperature gas and steam turbine deployment loops.

Features

• Eight independent hardware input channels dedicated to resistive thermal measuring apparatus
• Fully integrated onboard power supply sub-components independent of primary bus lines
• Exhaustive conformal style circuit layer treatment applied thoroughly across the base board structure
• Dual lateral communication ports enabling active network redundancy over standard control logic paths

Applications

• Industrial steam and gas turbine thermal parameter observation loops
• Multi-channel RTD signal processing inside standard industrial processing facilities
• Distributed thermal automation feedback controls requiring hazardous location approvals

Technical Specifications

Installation Guidelines

• Hazardous Site Interfacing: Secure matching compatibility with authorized terminal board units like the IS200TRTDH2D, IS200SRTDH1A, or IS200SRTDH2A when installing inside locations categorized under dangerous parameters.
• Input Isolation Constraints: Restrict incoming branch connections exclusively to passive, simple resistive instruments like standard RTDs; do not introduce active voltage feeds to the tracking ports.
• Insulation Parameters: Utilize interconnect cables equipped with temperature and dielectric properties that precisely fit all localized electrical authority codes.
• Diagnostic Monitoring: Observe the local front panel indicator lights including the dedicated Power, ATTN, and dual Ethernet connection tracking LEDs to confirm successful initialization status.

Compliance and Certifications

• CE Marked
• UL Listed
