Honeywell TP-DIKBTA-100 Experion PKS IKB Keyboard with Trackball

Description

The TP-DIKBTA-100 is an industrial-tier operator input hardware interface designed as an IKB Keyboard with Trackball for integration within Honeywell Experion PKS human-machine interface (HMI) consoles. This robust peripheral device provides process operators with reliable tactile text entry and cursor manipulation capabilities across distributed control system (DCS) master engineering and monitoring stations. Engineered to withstand sustained operational wear typical of centralized plant environments, it consolidates key entry layouts with an integrated trackball unit to minimize console spatial requirements. The hardware interacts directly with system operator stations to allow prompt loop manipulation, display Navigation, and rapid alarm acknowledgement sequences.

Features

• Integrated ergonomic trackball point device for precise, smooth cursor management.
• Heavy-duty industrial membrane or mechanical structure resilient against airborne debris.
• Standardized keyboard matrix mapping for native alignment with Honeywell console environments.
• Robust mechanical housing designed for drop-in desktop positioning or panel console mount setups.

Applications

• Centralized Control Room (CCR) operator console input infrastructure.
• Distributed Control Systems (DCS) parameter and setpoint adjustment stations.
• Process monitoring HMI interface platforms in chemical, gas, and refining plants.
• Operator engineering and utility configuration desks inside power generation facilities.

Technical Specifications

Installation Guidelines

Panel Mounting and Placement

Position the hardware flatly inside the designated enclosure cutout or desk space allocation. Ensure the base structure seats evenly across all surface corners to avoid chassis flexing or mechanical stress on internal contact circuits during continuous key strikes.

Cable Routing and EMI Mitigation

Route the interface connection cables through dedicated structural wireways inside the desk or console rack. Maintain adequate separation from primary power lines or fluctuating heavy electrical loads to limit the induction of high-frequency electromagnetic field interference on the interface lines.

Moisture and Contamination Protection

Although designed for harsh control room applications, safeguard the tracking ball assembly from continuous direct contact with oily fluids or heavy particulate settling. Clean the trackball cavity periodically according to standard site preventative procedures to maintain uninterrupted optical or mechanical tracking registration.

Grounding

Verify that the metal frame or structural housing enclosing the operator terminal desk has a low-impedance bond link to the principal plant instrument grounding bus to isolate static discharge during routine operational interaction.

FAQ

What is the core function of this peripheral assembly?

It acts as the primary hardware operator interface providing text entry and navigation capabilities for console stations.

Does this keyboard include a built-in pointing component?

Yes, the hardware features an integrated trackball assembly situated directly within the chassis to eliminate the need for an external mouse.

Is this unit compatible with Experion PKS control console systems?

Yes, it is designed precisely to interface with Honeywell industrial operator console frames and engineering computers.

What is the total weight of this product package during transit?

The gross shipping weight of the module kit and its protective container is rated at 10 Kg due to its heavy-duty industrial casing.

Can the trackball component be maintained or cleaned by field technicians?

Yes, standard maintenance steps allow for cleaning the tracking sphere cavity to remove collected dust or friction residue.

How does this hardware handle high-use continuous operation?

The keys and pointer are constructed with industrial-grade wear properties to guarantee precise feedback and loop execution lifespan over extended shifts.

What mounting styles are typically used for this hardware setup?

The device can be installed directly as a freestanding desktop unit or mounted flush into custom control center panel desks.

Does this device require proprietary software setup profiles on the station?

It pairs with standard Honeywell station driver environments built into the pre-configured industrial operating platforms.

What is the advantage of an integrated trackball over a separate industrial mouse?

It reduces clutter on the operator desk surface and avoids cursor tracking failures caused by uneven work surfaces.

How should the data cables be positioned inside the cabinet to prevent damage?

Cables must be laid out with sufficient strain relief loops and secured away from moving mechanical drawer slides.
