Delivering precise motion control in demanding automation setups, the Mitsubishi Electric HF-SN102BJ-S100 operates as a medium-inertia rotary actuator designed for high-performance positioning systems. This motor belongs to the robust HF-SN Series, engineered to handle structural mechanical configurations with optimal speed-to-torque characteristics. Outfitted with an integrated electromagnetic brake and a robust oil seal, this motor provides reliable holding torque and shaft protection in harsh operating conditions. Its high-grade environmental sealing makes it suitable for wet, dusty, or high-vibration manufacturing environments.

Features

  • High Torque Density: Engineered with a rated output of 1.0 kW to deliver consistent torque across its speed range.
  • Integrated Electromagnetic Brake: Built-in safety braking mechanism provides secure position retention and emergency deceleration.
  • Protective Oil Seal: Pre-installed shaft oil seal prevents the ingress of lubricants, cutting fluids, and coolants.
  • IP67 Environmental Rating: Sealed enclosure protects the internal windings and stator against dust and water immersion.
  • High Dynamic Response: Medium-inertia rotor design allows for excellent tracking control and stable operation under fluctuating loads.

Applications

  • Machine Tool Axes: Precise feed-rate control for multi-axis milling, turning, and grinding machinery.
  • Material Handling Systems: Dynamic positioning in automated storage, retrieval systems (ASRS), and transfer lines.
  • Packaging Equipment: High-speed indexing, filling, cartoning, and sealing applications.
  • Robotic Gantry Systems: Multi-axis overhead loaders requiring dependable holding braking.

Technical Specifications

Parameter Specification Value
Manufacturer Mitsubishi Electric
Model Number HF-SN102BJ-S100
Series Group HF-SN
Rated Output Power 1.0 kW
Rated Rotational Speed 2000 r/min
Electromagnetic Brake Integrated (Brake Included)
Oil Seal Integrated (Oil Seal Included)
IP Protection Rating IP67 (excluding shaft-through portion)
Inertia Class Medium Inertia
Shipping Weight (Calculated) 10.5 kg

Installation & Setup Guidelines

CRITICAL WARNING:

Ensure all upstream power supplies (main circuit and control circuit) are fully de-energized, locked out, and tagged out before beginning any wiring or mechanical mounting procedures. Confirm that the servo amplifier’s charge LED is fully extinguished to prevent risk of severe electric shock from residual bus voltage.

1
Mechanical Mounting: Mount the motor securely onto a flat, rigid metal surface. Proper heat dissipation depends on the motor being securely bolted to an appropriately sized heat-sink frame. Align the coupling carefully to avoid exceeding specified radial and thrust shaft loads.
2
Wiring & Shielding: Connect the power cables (U, V, W, and Ground) and encoder cables using matched, shielded industrial-grade connections. Ground the motor chassis frame to the main protective earth (PE) terminal of the control cabinet to suppress electromagnetic interference (EMI).
3
Brake Power Supply: Provide a dedicated, stabilized 24V DC power source for the electromagnetic brake. Do not share this power line with the 24V DC control power of the PLC or input sensors, as inductive flyback spikes from the brake coil can disrupt control logic.
