HG-SR52BJ

Mitsubishi Electric

Mitsubishi Electric HG-SR52BJ HG-SR Series AC Servo Motor

SKU HG-SR52BJ

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: HG-SR52BJ
  • Origin United States
  • Product Type: AC Servo Motors
  • Payment: T/T, Western Union
  • Weight: 8.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

AC Servo Motors HG-SR Series
Quantity
Call sales Contact

Product Description

Description

Designed for precise industrial motion control, the HG-SR52BJ is a high-performance rotary servo motor belonging to the Mitsubishi Electric HG-SR Series. This motor delivers a nominal output of 0.5 kW and operates at a rated speed of 2000 r/min. It is equipped with an integrated electromagnetic brake and a built-in oil seal to ensure reliable holding torque and enhanced protection against environmental contaminants. Optimized for dynamic responsiveness, the unit provides stable torque performance across its speed range, making it suitable for a variety of demanding positioning applications.

Features

  • Integrated Electromagnetic Brake: Provides robust holding capability during power-off or emergency conditions.
  • Pre-installed Oil Seal: Safeguards internal motor components against oil mist and fluid splashes.
  • Thermal Protection Class 155 (F): Offers high thermal resistance and insulation stability under continuous heavy loads.
  • Optimized Vibration Resistance: Certified to vibration rank V10, ensuring mechanical stability in heavy industrial setups.

Applications

  • Packaging machinery and material handling systems
  • CNC machine tools and automated assembly lines
  • Textile machinery and printing presses
  • Robotic joint positioning and pick-and-place systems

Technical Specifications

Parameter Specification Value
Manufacturer Mitsubishi Electric
Model HG-SR52BJ
Series HG-SR Series
Rated Output 0.5 kW
Rated Speed 2000 r/min
Maximum Torque 7.2 Nm
Rated Current 2.9 A
Electromagnetic Brake Yes (With)
Oil Seal Yes (With)
Insulation Class 155 (Class F)
Vibration Rank V10
Thermistor None
Environment Indoors (no direct sunlight), free from corrosive gas, flammable gas, oil mist, dust, and dirt
Weight 6.7 kg
Shipping Weight 8.0 kg

Installation Guidelines

  • Environmental Conditions: Mount the motor indoors in a well-ventilated location free from direct sunlight, corrosive chemicals, and explosive or flammable gases.
  • Shaft Alignment: Ensure accurate alignment with the driven shaft using high-quality flexible couplings to prevent premature bearing wear.
  • Grounding: Ensure the motor frame is securely grounded according to local industrial electrical codes to minimize electromagnetic interference.
  • Thermal Management: Maintain unobstructed airflow around the motor body to support correct heat dissipation.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the purpose of the 'B' and 'J' suffixes in the model number HG-SR52BJ?
The 'B' suffix designates that the motor is equipped with an integrated electromagnetic brake, while the 'J' suffix indicates the presence of an oil seal.
What is the rated power and torque of the HG-SR52BJ servo motor?
The motor has a rated output of 0.5 kW (500 W) and can achieve a maximum torque of 7.2 Nm.
What environmental conditions are required for operating this motor?
The HG-SR52BJ must be installed indoors, away from direct sunlight, and in environments free from corrosive or flammable gases, excessive oil mist, dust, and dirt.
Does the HG-SR52BJ include a built-in thermistor?
No, this specific model does not include a built-in thermistor.
