Omron CP1L-M40DT1-D CP1L Series High Performing Programmable Controller

Description

The Omron CP1L-M40DT1-D is a high-performing programmable logic controller designed for industrial automation tasks requiring a high degree of processing speed and compact integration. This CPU unit features a memory capacity of 10K steps and functions as the primary control block for small-to-medium machines. It comes equipped with integrated discrete I/O comprising 24 inputs and 16 transistor sourcing outputs, alongside embedded Ethernet connectivity for horizontal and vertical network communication. The controller supports motion control functions via high-speed counters and pulse outputs, ensuring compatibility with standard servo systems and factory automation architectures.

Features

• Embedded Ethernet connectivity for data exchange and system programming.
• 10K steps internal memory capacity for sequence logic.
• High-speed counter inputs supporting 4 axes at up to 100 kHz.
• Dedicated pulse outputs supporting 2 axes at up to 100 kHz.
• Onboard configuration of 40 local digital I/O points.
• Sourcing transistor outputs suitable for driving DC control circuits.

Applications

• Material handling systems and sorting conveyors.
• Automated packaging machinery and labeling systems.
• Small multi-axis positioning stages and pick-and-place units.
• Dedicated assembly machines and production workstations.
• Pumping, HVAC, and auxiliary system monitoring interfaces.

Technical Specifications

Performance

Power Requirements

Input/Output

Communication

Installation Guidelines

• DIN Rail Mounting: Secure the controller to standard 35mm DIN rail tracks inside an industrial enclosure, utilizing the integrated locking clips.
• Orientation and Cooling: Mount the hardware horizontally to maintain proper vertical convection airflow across the internal components.
• Wiring Polarity: Ensure correct DC voltage polarity is maintained at the power supply terminals before energizing the circuit.
• Signal Separation: Route 24 VDC I/O lines and Ethernet communication cables away from high-power AC lines or motor drives to avoid EMI.
• Grounding: Establish a solid ground connection directly from the functional ground terminal to a low-impedance earth point.

FAQ

• What type of outputs are available on this CPU unit?
• It features 16 sourcing transistor outputs (PNP configuration).
• Does this unit have built-in network ports?
• Yes, it features an embedded Ethernet port for communication and system integration.
• What is the total number of built-in I/O points?
• The unit contains a total of 40 integrated I/O points, consisting of 24 inputs and 16 outputs.
• What is the total program memory capacity?
• The memory capacity of this controller is rated at 10K steps.
• What type of power supply does this hardware require?
• It is designed to operate on a DC power supply.
• What is the maximum frequency for the high-speed counters?
• The high-speed counters operate up to a frequency of 100 kHz across 4 separate axes.
• Can this controller drive pulse-controlled motion axes?
• Yes, it includes 2 axes of pulse outputs capable of running up to 100 kHz.
• What series does this CPU unit belong to?
• It belongs to the Omron CP1L compact programmable controller family.
• Are the transistor outputs sinking or sourcing?
• The outputs are explicitly configured for sourcing (PNP) operation.
• Is special hardware needed to use the high-speed counting functions?
• No, the 4 axes of 100 kHz high-speed counters are embedded directly into the CPU.
