Omron CS1W-IA111 Input Module

Description

The CS1W-IA111 is an AC/DC Input Module designed for Omron’s high-performance CS1 series PLC system. This unit provides 16 digital input points, allowing the PLC to monitor external signal devices such as limit switches, sensors, or pushbuttons operating within a 100 to 120 VAC/VDC voltage range.

As part of the CS1 Basic I/O classification, this module is built for industrial durability and reliable data acquisition. It features a removable terminal block, which simplifies installation and replacement during system maintenance without requiring the rewiring of individual signal cables. It is a fundamental component for building robust control systems in manufacturing, processing, and automation environments.

Features

• Series: Omron CS1 Basic I/O
• Input Points: 16 points for multi-channel signal monitoring
• Voltage Compatibility: Supports 100 to 120 VAC/VDC
• Ease of Maintenance: Features a removable terminal block for efficient field service
• System Integration: Designed for seamless mounting and communication within the CS1 PLC rack architecture
• Efficiency: Low current consumption (0.11 A from the 5V system)

Applications

• Monitoring 110V industrial control circuits and safety relays
• Signal acquisition from limit switches and proximity sensors in large-scale machinery
• Feedback loops for panel-mounted operator pushbuttons and status indicators
• Interfacing with standard AC industrial field devices

Technical Specifications

Installation Guidelines

• Mounting: The module slides directly into the CS1 PLC backplane. Ensure the module is securely locked into the rack to maintain stable electrical contact with the backplane bus.
• Wiring: Use appropriate wire gauges for the terminal block. Since this module handles 100-120V, ensure that all safety protocols for high-voltage wiring are followed.
• Grounding: While the module is isolated, ensure the PLC rack itself is connected to a high-quality chassis ground to prevent noise interference.
• Safety: Always power down the PLC rack before inserting or removing the I/O module to prevent potential electrical arcing or damage to the module pins.
