Omron NS10-TV00B-ECV2 NS Series HMI

SKU NS10-TV00B-ECV2

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Omron
Product No.: NS10-TV00B-ECV2
Country of origin:Japan
Product Type: Human-Machine Interfaces
Payment: T/T, Western Union
Weight: 2300g
Shipping port: Xiamen
Warranty: 12 months

Description

Industrial control architectures requiring robust visualization capabilities frequently utilize the Omron NS10-TV00B-ECV2 operator interface. Operating within the high-performance NS Series, this human-machine interface (HMI) provides a clear and responsive monitoring platform for automated machinery and plant systems. Equipped with a 10.4-inch TFT active-matrix color display, the unit ensures high visibility and precise data representation for real-time monitoring and parameter adjustment.

The system integrates an analog resistive touch panel that removes layout limitations common to matrix-style screens, enabling flexible positioning of buttons, charts, and input fields. Outfitted in a durable black enclosure, the unit features an LED backlight designed for longevity and reduced energy draw, ensuring continuous operation in harsh manufacturing environments.

Features

High-visibility 10.4-inch TFT color LCD displaying sharp operational data.
Analog resistive touch screen allowing precise, multi-point placement of control elements.
Energy-efficient LED backlight offering reliable display performance over extended life cycles.
Built-in communications interface supporting seamless integration with Omron PLCs and external automation systems.
Rugged industrial enclosure with a black bezel suitable for cabinet mounting.

Applications

Automated assembly and manufacturing machinery.
Packaging, labeling, and filling equipment.
Water treatment facility monitoring panels.
Material handling and conveyor system control centers.
Food processing and chemical batching units.

Technical Specifications

ParameterSpecification

Manufacturer	Omron
Part Number/Model	NS10-TV00B-ECV2
Series	NS Series
Display Type	10.4-inch TFT Color LCD
Resolution	640 x 480 dots (VGA)
Touch Panel Type	Analog resistive
Backlight Type	LED
Case Color	Black
Weight	2.3 kg

Connections and Interfaces

Port / ConnectorFunction

Ethernet Port	Host communications and programming download (10Base-T/100Base-TX)
Serial Port A (RS-232C)	Connection to PLC, temperature controllers, or peripheral devices
Serial Port B (RS-232C)	Secondary serial device communications
USB Master Port	Data storage and transfer via USB flash drive
USB Slave Port	Direct connection to computer for screen design transfer

Installation Guidelines

Panel Mounting: Install the device into a panel cutout of corresponding size, ensuring the waterproof packing is correctly seated to maintain IP65 protection.
Power Supply: Connect to a stable 24V DC power source. Ensure the grounding terminal is connected directly to a dedicated class-D ground (100 Ohms or less resistance) to mitigate electrical noise.
Thermal Management: Maintain a minimum clearance of 100 mm around the top, bottom, and sides of the unit to ensure adequate ventilation. Avoid installation areas with direct sunlight or high radiant heat.
Cable Routing: Keep communication cables separated from high-voltage AC lines to prevent signal interference.

FAQ

What is the resolution of the Omron NS10-TV00B-ECV2?

The display features a standard VGA resolution of 640 x 480 dots on a 10.4-inch TFT color LCD.

What touch panel technology does this HMI use?

It is equipped with an analog resistive touch panel, which allows for free placement of custom control buttons and interfaces.

Does the NS10-TV00B-ECV2 feature an Ethernet port?

Yes, the 'E' designation in the model suffix indicates the presence of a built-in Ethernet port for network communications and program transfers.

How much does the unit weigh?

The net weight of the Omron NS10-TV00B-ECV2 HMI is 2.3 kg.
