Manufacturer: Omron
Product No.: NS10-TV00B-ECVW
Country of origin:Japan
Product Type: Programmable Terminals
Payment: T/T, Western Union
Weight: 8000g
Dimensions: 350 x 290 x 140 mm
Shipping port: Xiamen
Warranty: 12 months
Providing human-machine interface control in heavy-duty industrial automation systems, the Omron NS10-TV00B-ECVW is a 10.4-inch TFT color display terminal engineered for dependable visualization and operator interaction. Operating on 24 VDC power, this screen unit utilizes a high-visibility 640 x 480 dot VGA screen, providing clear system status readouts without the need for an integrated network controller. Built with a sleek black bezel, it interfaces natively with Omron PLCs and secondary controllers via dual serial links, eliminating software overhead through pre-configured screen components.
| Manufacturer | Omron |
| Model Number | NS10-TV00B-ECVW |
| Series | NS Series |
| Display Size | 10.4-inch |
| Resolution | 640 x 480 VGA |
| Display Type | TFT Color LCD |
| Ethernet Port | None (No) |
| Serial Interfaces | 2 x RS-232C (D-Sub 9-pin) |
| Case Color | Black |
| Operating Voltage | 24 VDC |
| Operating Temperature Range | 0 to 50 degC |
| Certifications & Standards | cULus, CE |
| Shipping Weight (Calculated) | 3.20 kg |
| Package Dimensions (Calculated) | 350 x 290 x 140 mm |
| Connector Pin / Terminal | Function / Circuit Assignment |
|---|---|
| Serial Port A (D-Sub 9-pin Female) | RS-232C Link to PLC or Host Controller |
| Serial Port B (D-Sub 9-pin Female) | RS-232C Secondary Channel or Peripheral Connection |
| USB Slave Port (Type-B) | Programming Upload / Download Port |
| Power Input Terminals | 24 VDC, 0 VDC, Frame Ground (FG) |
This model functions as a direct physical and functional replacement for previous revisions of the 10.4-inch NS10 series panels. Existing projects configured for standard NS10-TV00B terminals can be deployed directly onto the ECVW variant without graphical conversions using CX-Designer software. Keep in mind that as a serial-only unit (TV00B), it cannot host EtherNet/IP tags directly; network projects must be converted to Host Link or Sysmac Way serial communication protocols.
Ensure that the panel cooling vents are never obstructed when installed in unventilated enclosures. If the ambient temperature inside the panel rises above 50 degC, it will accelerate the decay profile of the cold cathode backlight. To minimize visual ghosting and touch registration offsets, ground the terminal directly to the enclosure mounting plate with a short, low-impedance copper strap.
When building RS-232C communication lines for this panel, always use double-shielded twisted-pair cabling for runs extending beyond 3 meters. Keep these communication cables separated from motor power cables or variable frequency drive output paths by at least 150 mm to avoid noise disruption or packet dropouts.
CRITICAL WARNING
Before starting installation or maintenance, disconnect all electrical power sources. Verify complete discharge of electrical charges from neighboring control devices to avoid electric shock risks and damage to sensitive CMOS interface chips.
