Omron TP70-1A2 On-Site Flexible Rod Switch

Description

Designed for robust position detection and limit control in demanding industrial environments, the Omron TP70-1A2 functions as a high-reliability flexible rod switch configured with an integrated switch design. This heavy-duty electromechanical switch is equipped with a D4N-2187 built-in switch mechanism, engineered specifically for base mounting with integrated height adjustment capabilities. This design ensures highly customizable alignment for conveyor monitoring, machinery protection, and process positioning controls under rigorous operating conditions.

Features

• Equipped with a highly reliable D4N-2187 internal built-in switch core.
• Robust IP65 environmental rating protecting against dust and liquid ingress.
• Base mounting configuration with adjustable height options for precise mechanical alignment.
• High mechanical vibration and shock tolerance for continuous industrial performance.
• Secure screw terminal connection interface to prevent wire disconnection under mechanical stress.

Applications

• Conveyor belt drift and alignment monitoring systems.
• Material handling, sorting, and packaging lines.
• Heavy machinery limit control and position detection.
• General manufacturing and factory automation systems.

Technical Specifications

Installation Guidelines

• Mount the base securely to a rigid surface capable of absorbing physical impacts and vibrations.
• Utilize the height adjustment mechanism to set the precise vertical position of the flexible rod relative to the actuator path.
• Ensure that screw terminals are torqued to specifications to maintain contact integrity.
• Apply appropriate sealing to cable conduits to preserve the IP65 environmental protection rating.
