Schneider Altistart 01 ATS01N222LU Soft Starter

Description

The ATS01N222LU is an Altistart 01 soft starter engineered for the controlled starting and stopping of asynchronous motors. This unit is rated for a nominal current of 22 A and operates within a voltage range of 200–240 V, supporting motor power ratings between 4 kW and 5.5 kW. Designed to reduce mechanical stress and electrical surges during motor startup, the ATS01N222LU provides a smooth acceleration profile, extending the operational lifespan of drive components such as belts, gears, and couplings. It is a compact and efficient solution for small-to-medium motor applications requiring reliable performance in a wide range of industrial environments.

Features

• Controlled starting and stopping for asynchronous motors
• 22 A nominal current rating
• 200–240 V operating voltage range
• Supports motor power ratings from 4 kW to 5.5 kW
• Compact design for space-saving panel installation
• Reduced mechanical wear on motor-driven systems

Applications

• Conveyor systems
• Small pumps and fans
• Packaging machinery
• Automated assembly lines
• Material handling equipment

Technical Specifications

Installation Guidelines

• Mounting: The soft starter should be mounted vertically to ensure optimal heat dissipation through the cooling fins.
• Ventilation: Maintain adequate clearance around the unit in the control panel to allow for airflow; avoid placing it near heat sources.
• Wiring: Connect the power lines and motor leads according to the provided wiring diagram. Ensure that all terminals are tightened to the specified torque to prevent overheating.
• Settings: Configure the acceleration and deceleration ramps via the integrated adjustment potentiometers to suit the specific load requirements of the application.
• Environment: Ensure the device is installed in a clean, dry location free from corrosive gases, conductive dust, or excessive vibration.
