Schneider Altivar 12 ATV12HU30M3 Variable Frequency Drive

SKU ATV12HU30M3

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV12HU30M3
Country of origin:France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 2440g
Dimensions: 22cm x 21,5cm x 22cm
Shipping port: Xiamen
Warranty: 12 months

Description

The ATV12HU30M3 is a compact Altivar 12 variable frequency drive designed for simple industrial machines and commercial applications. Rated for 3 kW (4 HP), this drive operates on a 200-240 V three-phase supply. It is engineered for straightforward setup and integration, offering reliable speed control for small asynchronous motors in applications where ease of use and space efficiency are primary requirements.

Features

Power rating: 3 kW (4 HP)
Input voltage: 200-240 V (Three-phase)
Compact, space-saving design
User-friendly configuration and operation
Optimized for small-scale industrial and commercial motor control
Efficient speed regulation for asynchronous motors

Applications

Small conveyors
Pumping systems
Fan and ventilation units
Packaging machines
Commercial kitchen appliances (e.g., mixers, slicers)

Technical Specifications

Specification	Details
Manufacturer	Schneider Electric
Range	Altivar
Subrange	12
Product Type	Variable frequency drives
Power Rating	3 kW (4 HP)
Input Voltage	200-240 V (Three-phase)
Dimensions	22 x 21.5 x 22 cm
Weight	2.44 kg
Commodity Code	85044095
Product Status	Active

Installation Guidelines

Mounting: Mount the drive vertically on a flat, non-combustible surface. Maintain adequate clearance above and below the unit for airflow to ensure proper cooling.
Environmental: Protect the unit from dust, moisture, and corrosive vapors. Operating ambient temperatures must stay within the specified range to prevent thermal derating.
Wiring: Connect the three-phase power supply to the input terminals and the motor to the output terminals. Keep control signal wiring physically separate from power cabling to minimize electrical noise.
Grounding: Secure a solid connection to the system protective earth (PE) terminal to ensure operator safety and EMC performance.
Commissioning: Use the drive's built-in HMI to input motor parameters (such as nominal current and frequency) before initial startup to ensure accurate control.

FAQ

What is the power rating of the ATV12HU30M3?

This drive is rated for 3 kW (4 HP).

What voltage supply does this drive require?

The drive requires a 200-240 V three-phase power supply.

What is the current lifecycle status of the Altivar 12 series?

The Altivar 12 series is currently in the Active product lifecycle stage.

What are the physical dimensions of this drive?

The drive dimensions are 22 cm by 21.5 cm by 22 cm.

View all FAQs →

Quantity

Call sales Contact

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

Reviews

1 1

Only 9 item(s) left in stock

Quantity

View full details

Global Express Shipping

Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).

For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .

TECHNICAL SPECIFICATIONS

Color pattern	Black
Country of origin	France
