Schneider Altivar 61 ATV61HC13N4 Variable Frequency Drives

Description

The Schneider Electric ATV61HC13N4 is an Altivar 61 variable frequency drive designed for fluid management applications. Operating on a 380-480 V three-phase supply voltage, this inverter delivers a power capacity of 132 kW and a rated current of 259 A. Engineered to optimize pump and fan control systems, the drive features IP20 enclosure protection for indoor installations. Built with physical dimensions of 36 x 102.2 x 37.7 cm and a weight of 74.00 kg, it provides robust and reliable motor control performance. Although classified as a phase-out product, it remains a critical component for maintaining and supporting existing industrial drive architectures.

Features

• Altivar 61 variable frequency drive optimized for fluid management and pumping applications
• Supports 380-480 V three-phase operational voltage input
• Delivers a power capacity of 132 kW and a rated output current of 259 A
• Equipped with IP20 protection for standard indoor cabinet installations
• Phase-out product lifecycle status suitable for legacy system replacements

Applications

• Municipal and industrial water treatment plants
• Pumping stations and booster systems
• Large HVAC ventilation fans and blower systems
• Fluid management and industrial process control loops

Technical Specifications

Connections/Interfaces

Installation Guidelines

• Ensure all incoming power supplies and control circuits are completely de-energized before mounting or wiring the drive.
• Mount the drive vertically on a robust, load-bearing surface capable of supporting its 74.00 kg weight within an appropriate enclosure.
• Maintain recommended clearance spaces above and below the unit to ensure proper convective cooling and airflow.
• Connect incoming power lines, motor leads, and control wiring securely, ensuring proper grounding to minimize electromagnetic interference (EMI).
• Verify parameter settings and fault history before initial system startup and motor rotation tests.
