Schneider Altivar 950 ATV950U22N4 Variable Frequency Drive

SKU ATV950U22N4

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATV950U22N4
Country of origin:France
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 21000g
Dimensions: 80cm x 39cm x 54cm
Shipping port: Xiamen
Warranty: 12 months

Description

The ATV950U22N4 is an Altivar 950 variable frequency drive designed for demanding process control applications requiring high precision and reliability. Rated for 2.2 kW and operating on a 400-480 V three-phase supply, this upright frequency converter includes an integrated brake chopper for effective management of regenerative energy. Housed in an IP55-rated enclosure, the ATV950U22N4 provides superior protection against dust and water, making it a dependable solution for harsh industrial environments and complex motor control tasks.

Features

Power rating: 2.2 kW
Voltage compatibility: 400-480 V (Three-phase)
Integrated brake chopper for regenerative control
IP55 protection rating for protection against harsh environments
High-performance process control capabilities
Upright frequency converter design

Applications

High-precision process control systems
Industrial pumping and fluid management
Conveyor and material handling lines
Mixing and agitation equipment
Applications with high inertia or regenerative braking requirements

Technical Specifications

Specification	Details
Manufacturer	Schneider Electric
Range	Altivar
Subrange	950
Product Type	Variable frequency drives
Power Rating	2.2 kW
Input Voltage	400-480 V
Protection Rating	IP55
Dimensions	80 x 39 x 54 cm
Weight	21.00 kg
Commodity Code	85044095
Product Status	Active

Installation Guidelines

Mounting: Mount the drive vertically in an upright position. Ensure the supporting structure can accommodate the unit's weight and dimensions.
Cooling: Although IP55-rated, ensure sufficient clearance is maintained for thermal management to prevent internal overheating.
Wiring: Use appropriately shielded cables to connect the motor. Ensure the brake chopper connection is wired to a suitably rated external braking resistor if required by the application dynamics.
Grounding: A dedicated, low-impedance earth connection to the chassis is essential for safety and to minimize electromagnetic interference.
Protection: Ensure that input power is protected by appropriate circuit breakers or fuses as per the manufacturer's technical documentation.

FAQ

What is the primary function of the integrated brake chopper in this model?

The integrated brake chopper is used to manage regenerative energy, allowing for safe and controlled motor deceleration in applications with high inertia.

What level of ingress protection does the ATV950U22N4 offer?

This model features an IP55 rating, protecting the drive from dust ingress and water jets.

What is the rated power output for this drive?

The ATV950U22N4 is rated for a power output of 2.2 kW.

Is this drive suitable for harsh industrial environments?

Yes, its IP55 enclosure and robust Altivar 950 design are specifically engineered for challenging industrial conditions and high-precision processes.
