Schneider Electric 140XTS01209 Modicon Quantum Cable and I/O Connector Assembly

Only 8 item(s) left in stock

Manufacturer: Schneider Electric
Product No.: 140XTS01209
Country of origin:France
Product Type: PLC Cable and Connector Assemblies
Payment: T/T, Western Union
Weight: 1420g
Dimensions: 30.0 x 32.5 x 5.8 cm
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

Engineered to facilitate secure, high-capacity field wiring connections, the Schneider Electric 140XTS01209 functions as a dedicated 40-pin terminal block and 2.7-meter (9-foot) pre-wired cable interface assembly for the Modicon Quantum system. It bridges the gap between field-level control signals and high-power discrete I/O modules, streamlining cabinet organization while minimizing point-to-point wiring errors during installation.

Features

Pre-wired 40-pin connector layout configured specifically for high-power Modicon Quantum I/O architectures.
Integrated 2.7-meter (9-foot) industrial-grade cable jacketed for protection against oil, mechanical strain, and thermal variations.
Heavy-duty screw-terminal block configuration ensuring robust physical retention and electrical contact under high-vibration conditions.
Eliminates redundant terminal strip interfaces to minimize internal enclosure space requirements.

Applications

Modicon Quantum discrete and high-power digital I/O module field connections.
Heavy industrial control cabinet wiring and power distribution.
Retrofitting legacy automated systems where structural physical reliability is required.

Technical Specifications

Parameter	Specification Value
Manufacturer	Schneider Electric
Model Identifier	140XTS01209
Product Series	Modicon Quantum
Type of Product	Pre-Wired High-Power I/O Connector and Cable Assembly
Terminal Connection Type	40-Pin Terminal Strip (Module Side)
Cable Length	2.7 meters (9 feet)
Country of Origin	France
Net Weight	1.42 kg
Shipping Weight (Calculated)	1.85 kg
Module Dimensions	30.0 x 32.5 x 5.8 cm
Commodity Code	85444290 (Insulated Cable Assemblies)

Empirical Engineering Insights

Alternative Models & Compatibility

This assembly acts as a direct-fit replacement for applications requiring standard 40-pin Quantum high-power interfaces. When substituting or retrofitting shorter cable assemblies with this 2.7-meter model, avoid coiling excess line length in tight bundles, as this can introduce localized inductive coupling in heavy AC switching cabinets.

Application Pitfalls & Engineering Notes

Because this assembly is rated for higher power paths, ensure that the adjacent low-voltage communications wiring is routed through isolated wire trays. The 5.8 cm thickness of the terminal housing requires structural clearance inside the enclosure door swing; verify that the door layout does not compress or stress the terminal block connection joints.

Commissioning & Wiring Tips

Prior to final module engagement, use a calibrated torque driver to secure the terminal connector to the Modicon module frame. Under-torquing can lead to micro-arcs and high resistance over time, particularly on channels carrying full rated industrial currents.

Installation Guidelines

CRITICAL WARNING: ELECTRICAL HAZARD Isolate and de-energize all primary, auxiliary, and backplane power supplies before initiating the connection or removal of this wiring assembly. Failure to do so can cause structural damage to the Modicon Quantum I/O module backplane interfaces and poses severe risk of arc flash.

Inspect the 40-pin block socket layout for any bent or contaminated contacts prior to inserting into the PLC interface slot.

Align the connector firmly with the module mounting guide rails and press until it seats squarely.

Tighten the integrated mechanical fasteners to ensure long-term retention in high-vibration applications.

Key Features:

What is the function of the 140XTS01209 cable assembly?

It acts as a pre-wired high-power connector and cable interface that links field devices directly to the 40-pin input/output modules of a Modicon Quantum PLC system.

How long is the integrated cable on the 140XTS01209?

The cable assembly has a length of 2.7 meters, which is approximately 9 feet.

Can this connector be wired during PLC hot-swapping operations?

No. All field wiring, terminal block mounting, and adjustments must be conducted with the system fully de-energized to prevent short circuits and backplane damage.

What is the pin count and terminal connection style for this unit?

It is equipped with a 40-pin terminal strip on the module-facing side, utilizing robust screw connections designed for heavy-duty industrial field wiring.
