Schneider Electric Altivar 11 ATV11HU29M2E Variable Frequency Drives

Description

The ATV11HU29M2E is an Altivar 11 variable speed drive engineered by Schneider Electric for efficient motor control in light industrial machinery and commercial equipment. This compact frequency converter delivers a rated power output of 1.5 kW and operates on a 230V single-phase power supply. Housed in an IP20 rated enclosure, it is designed for indoor control cabinet installation, offering precise speed regulation and torque performance for asynchronous motors. Typical industrial applications include small packaging machines, commercial fans, centrifugal pumps, automated sliding doors, and small conveyor belts. It is fully compatible with standard Schneider Electric Altivar drive architectures and control terminals.

Features

• Altivar 11 variable speed drive designed for efficient AC motor control
• Rated power output of 1.5 kW for 230V single-phase electrical systems
• IP20 rated enclosure optimized for internal control cabinet mounting
• Compact profile and clear terminal markings for straightforward integration

Applications

• Small packaging and material handling machinery
• Commercial ventilation fans and air handling units
• Centrifugal pumps and fluid transfer systems
• Automated doors and small conveyor lines

Technical Specifications

Installation Guidelines

• Mount the variable frequency drive vertically onto a clean, solid, and grounded mounting plate inside the control cabinet.
• Maintain recommended clearance spaces above and below the drive housing to ensure proper thermal dissipation and cooling airflow.
• Connect the 230V single-phase power supply lines, motor cables, and control wiring using shielded cables in accordance with EMC guidelines.
• Verify parameter settings and terminal connections before energizing the drive system.
