Schneider Electric ATV71E5U15N4 Altivar 71 Variable Frequency Drive

Description

The ATV71E5U15N4 is a Schneider Electric Altivar 71 variable frequency drive (VFD), engineered for demanding industrial motor control applications. This drive provides a power rating of 1.5 kW (2 HP) and is designed for operation with 480 V supply voltages. It features an integrated EMC filter for reduced electrical noise and an IP54-rated enclosure, providing robust protection against dust and water splashes. The Altivar 71 series is known for its high-performance torque control and versatility, making it a reliable choice for complex speed-regulated processes.

Features

• Series: Altivar 71
• Power Rating: 1.5 kW / 2 HP
• Supply Voltage: 480 V
• EMC Protection: Integrated EMC filter
• Enclosure Rating: IP54 (dust and splash protection)

Applications

• Complex industrial machinery and automation
• High-precision torque control systems
• Pumping and ventilation systems in harsh environments
• Conveyors and material handling equipment
• Manufacturing and processing machinery

Technical Specifications

Installation Guidelines

• Mounting: The drive is intended for vertical mounting. Due to its IP54 rating, it can be installed in environments where limited dust and water protection is required; however, internal cabinet mounting is still recommended for extended service life.
• Environment: Ensure the operating ambient temperature is within specifications. Maintain clean intake vents to avoid overheating.
• Wiring: Connect the 3-phase power supply and motor leads securely. Ensure that shielded cables are used for the motor connection to benefit from the integrated EMC filter.
• Grounding: A solid earth connection is mandatory to comply with safety standards and ensure effective operation of the EMC filter.
• Ventilation: Confirm that the mounting location provides adequate clearance for natural or forced airflow.
