Schneider Electric ATV71HU75M3Z Altivar 71 Variable Frequency Drive

Description

The ATV71HU75M3Z is a Schneider Electric Altivar 71 variable frequency drive (VFD), tailored for high-performance motor control in industrial environments. This drive supports a power output of 7.5 kW (10 HP) and is designed for use with 240 V 3-phase supply voltages. It features an integrated EMC filter to mitigate electromagnetic interference and ensure reliable operation. Please note that this unit is supplied without a graphic terminal, allowing for flexible integration into systems where a centralized human-machine interface (HMI) is already provided.

Features

• Series: Altivar 71
• Power Rating: 7.5 kW / 10 HP
• Input Voltage: 240 V
• EMC Compatibility: Integrated EMC filter
• Configuration: Supplied without a graphic terminal

Applications

• Complex industrial machinery and automation
• High-precision torque control systems
• Pumping and fan control in industrial settings
• Material handling and conveyor systems
• Processing machinery requiring wide speed ranges

Technical Specifications

Installation Guidelines

• Mounting: Intended for vertical mounting inside an electrical control cabinet. Ensure sufficient clearance for proper airflow around the unit.
• Environment: Maintain an operating ambient temperature and humidity within specified limits. Keep the installation area free from conductive dust and corrosive gases.
• Wiring: Connect the 3-phase power supply and motor leads securely using appropriate cable gauges for a 7.5 kW load. Use shielded motor cables to benefit from the EMC filter.
• Grounding: Establish a solid, low-impedance ground connection from the drive housing to the system ground bus for safe operation and noise reduction.
• Interface: Since this model lacks an integrated graphic terminal, ensure you have an external HMI or diagnostic tool available for initial commissioning and parameter configuration.
