Schneider Modicon Premium TSXCAY22C Motion Control Module

SKU TSXCAY22C

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: TSXCAY22C
Country of origin:France
Product Type: Control Modules
Payment: T/T, Western Union
Weight: 560g
Shipping port: Xiamen
Warranty: 12 months

Description

The TSXCAY22C is a motion control module specifically engineered for the Modicon Premium automation platform to provide precise management of servo motors. This module supports the control of up to 2 independent axes, allowing for synchronized or autonomous motion profiling in demanding industrial applications. With a versatile operating range spanning from 8 ms to 10 s, it offers the flexibility required to execute complex motion sequences. As a key component of the Modicon Premium range, the TSXCAY22C ensures reliable integration and operational stability for high-precision manufacturing and process automation systems.

Features

Dedicated motion control for servo motor systems
2-axis independent control capability
Flexible timing range (8 ms to 10 s)
Seamless integration with Modicon Premium rack architecture
High-precision signal processing for industrial motion tasks

Applications

Multi-axis machine tool positioning
Automated assembly and pick-and-place equipment
Precision conveyor and synchronization systems
Packaging machinery
Customized motion sequences in production lines

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Modicon Premium
Product Type	Motion control module
Axis Capacity	2 Axes
Timing Range	8 ms to 10 s
Product Phase	Phase-Out
Weight	0.56 kg
Commodity Code	85371099
Export Control Regulations	N

Installation Guidelines

Rack Integration: Install the module into a compatible Modicon Premium rack slot. Ensure the backplane connector is fully seated and the retaining screws are tightened to secure the unit against mechanical shock.
Wiring: Use high-quality shielded cabling for communication between the module and servo drives to prevent signal distortion or interference in high-speed motion loops.
Grounding: Establish a robust common ground for the motion control system to eliminate potential differences between the module, drives, and motors, which can cause erratic axis movement.
Configuration: Utilize the appropriate programming software to map the motion profiles to the control module. Verify axis parameters and limit switches before initiating live motor movement.
Safety Precautions: Integrate external hardware emergency stop circuits that bypass the module to ensure machine safety in the event of controller failure.

FAQ

How many axes can the TSXCAY22C control?

This module is capable of controlling up to 2 independent axes for servo motor applications.

What is the primary application of this module?

The TSXCAY22C is designed for high-precision motion tasks, including positioning, synchronization, and profiling in industrial automation.

What does the 8 ms to 10 s range refer to?

This range represents the flexibility in timing and motion sequence execution parameters supported by the module.

Is this module compatible with other PLC series?

The TSXCAY22C is specifically engineered for the Modicon Premium platform and is optimized for its rack architecture and communication bus.

View all FAQs →
