Siemens 6AV7861-3AA00-1AA0 SIMATIC FP Flat Panel

Siemens 6AV7861-3AA00-1AA0 SIMATIC FP Flat Panel

Only 4 item(s) left in stock

  • Manufacturer: Siemens

  • Product No.: 6AV7861-3AA00-1AA0

  • Country of origin:Germany

  • Product Type: Flat Panel

  • Barcode: 85371091

  • Payment: T/T, Western Union

  • Weight: 12720g

  • Dimensions: 51.00 x 62.50 x 24.00 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

View full details
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

The Siemens 6AV7861-3AA00-1AA0 is a SIMATIC Flat Panel 19, a 19-inch TFT screen designed for industrial visualization applications. It features a resolution of 1280x1024 pixels and operates on a 24 V DC power supply. Connectivity is provided via VGA and DVI-D interfaces, and it includes a 1.8 m VGA cable for immediate integration into existing systems. This flat panel is suitable for use as an operator interface or display unit in various industrial environments.

Features

  • 19-inch TFT display
  • 1280x1024 pixel resolution
  • 24 V DC power supply
  • VGA and DVI-D interfaces
  • Includes 1.8 m VGA cable

Applications

  • Industrial visualization systems
  • Operator interface for control systems
  • Machine control panels
  • Process monitoring displays

Technical Specifications

Manufacturer Siemens
Product Range SIMATIC
Subrange FP
Product Type Flat Panel
Screen Size 19-inch
Display Type TFT
Resolution 1280x1024 pixels
Power Supply 24 V DC
Interfaces VGA, DVI-D
Included Cable VGA cable 1.8 m
Product Phase Obsolete
Successor Model 6AV7861-3AA00-2AA0
Package Dimensions (Calculated) 51.00 x 62.50 x 24.00 cm
Shipping Weight 12.72 kg
Commodity Code 85371091
Export Control Regulations (ECCN) EAR99

Installation Guidelines

  1. De-energize System: Before commencing installation, ensure all power to the system and the flat panel's intended mounting location is completely de-energized and locked out.
  2. Mounting: Securely mount the flat panel in its designated enclosure or panel cutout. Ensure proper ventilation space around the unit to prevent overheating.
  3. Power Connection: Connect the 24 V DC power supply to the designated terminals, observing correct polarity. Verify the power source meets the specified voltage requirements.
  4. Video Connection: Connect the appropriate video cable (VGA or DVI-D) from the host system's video output to the corresponding input on the flat panel. The 1.8 m VGA cable is included for convenience.
  5. Grounding: Ensure the flat panel is properly grounded according to local electrical codes and manufacturer recommendations to enhance safety and reduce electromagnetic interference.
  6. Cable Management: Route all cables to prevent strain, sharp bends, and interference with other components. Use cable ties or conduits as necessary.
  7. Power On: After all connections are verified, re-energize the system and the flat panel. Test display functionality and interface communication.
Key Features:
#Flat Panel #SIMATIC FP

What is the screen size and resolution of the 6AV7861-3AA00-1AA0?
The flat panel features a 19-inch TFT screen with a resolution of 1280x1024 pixels.

What power supply is required for this SIMATIC Flat Panel?
It requires a 24 V DC power supply for operation.

What video interfaces does the 6AV7861-3AA00-1AA0 support?
The flat panel supports both VGA and DVI-D interfaces, and a 1.8 m VGA cable is included.

Is the Siemens 6AV7861-3AA00-1AA0 still an active product?
No, this product is currently in an obsolete phase.

What is the successor model for this flat panel?
The successor model for the 6AV7861-3AA00-1AA0 is the 6AV7861-3AA00-2AA0.
