Siemens

Siemens 6AV7881-3AA00-3DG0 SIMATIC IPC277D NanoPanel PC

SKU 6AV7881-3AA00-3DG0

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: Siemens

  • Product No.: 6AV7881-3AA00-3DG0

  • Country of origin:Germany

  • Product Type: NanoPanel PC

  • Barcode: 85371098

  • Payment: T/T, Western Union

  • Weight: 3300g

  • Dimensions: 18.00 x 23.50 x 25.00 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The Siemens 6AV7881-3AA00-3DG0 is a SIMATIC IPC277D NanoPanel PC featuring a 12-inch Touch TFT display. This industrial panel PC is equipped with an Atom E640 (1.0 GHz) processor, 1 GB RAM, and an 8 GB SIMATIC PC CompactFlash pre-installed with Windows Embedded Standard 7 SP1 (WES 7 SP1). It provides robust connectivity with two 10/100/1000 Mbps Ethernet RJ45 ports, three high-current USB V2.0 ports, and one serial (COM 1) interface. A Compact Flash slot is included for additional storage flexibility. The unit operates on a 24 V DC power supply and comes with WinCC Advanced RT V13 (512 Power Tags), including logging and recipes, along with a WinCC RT Advanced V14 License Package, making it suitable for various HMI and control applications.

Features

  • 12-inch Touch TFT Display
  • Integrated Atom E640 (1.0 GHz) Processor
  • 1 GB RAM
  • 8 GB SIMATIC PC CompactFlash with pre-installed WES 7 SP1
  • Pre-installed WinCC Advanced RT V13 (512 Power Tags, including logging and recipes)
  • WinCC RT Advanced V14 License Package
  • Two 10/100/1000 Mbps Ethernet RJ45 Ports
  • Three USB V2.0 Ports (High Current)
  • One Serial (COM 1) Interface
  • Compact Flash Slot for expandable storage
  • 24 V DC Power Supply

Applications

The Siemens 6AV7881-3AA00-3DG0 NanoPanel PC is typically deployed in industrial environments for:
  • Human Machine Interface (HMI) applications
  • Process visualization and control
  • Data acquisition and monitoring
  • Machine operation and diagnostics
  • Embedded control systems requiring a compact, robust PC platform

Technical Specifications

Attribute Value
Brand Siemens
Manufacturer Siemens
Range Simatic Panel PC
Subrange IPC277D
Product Type NanoPanel PC
Display Type 12" Touch TFT
Processor Atom E640 (1.0 GHz)
RAM 1 GB
Storage 8 GB SIMATIC PC CompactFlash
Operating System WES 7 SP1 (Windows Embedded Standard 7 Service Pack 1)
Pre-installed Software WinCC Advanced RT V13 (512 Power Tags, including logging and recipes), WinCC RT Advanced V14 License Package
Ethernet Ports 2x 10/100/1000 Mbps RJ45
USB Ports 3x USB V2.0 (High Current)
Serial Ports 1x (COM 1)
Expansion Slot Compact Flash slot
Power Supply 24 V DC
PLM Product Phase Phase-Out
Package Dimensions 18.00 x 23.50 x 25.00 cm
Shipping Weight 3.30 kg
Commodity Code 85371098
Export Control Regulations (ECCN) N
Country of Origin Not specified in source data

Connections / Interfaces

The 6AV7881-3AA00-3DG0 NanoPanel PC provides the following interfaces:
  • Ethernet: Two RJ45 ports supporting 10/100/1000 Mbps for network integration.
  • USB: Three USB V2.0 ports, designed for high current devices, for peripheral connections.
  • Serial: One serial port (COM 1) for legacy device communication or specific industrial protocols.
  • Compact Flash: A dedicated slot for Compact Flash cards, enabling flexible and expandable storage solutions.

Installation Guidelines

Proper installation ensures reliable operation and longevity of the NanoPanel PC.
  1. De-energize System: Before beginning any installation or wiring, ensure that all power to the control system and the NanoPanel PC is disconnected and locked out.
  2. Mounting: Securely mount the NanoPanel PC in a suitable panel cutout or enclosure, ensuring adequate ventilation and clearance for cable routing and maintenance.
  3. Power Connection: Connect the 24 V DC power supply to the designated terminals, observing correct polarity. Ensure the power supply meets the specified voltage and current requirements.
  4. Grounding: Establish a proper protective earth (PE) connection to the NanoPanel PC chassis to minimize electrical noise and ensure safety.
  5. Ethernet Connections: Connect standard RJ45 Ethernet cables to the 10/100/1000 Mbps ports for network communication.
  6. USB Peripherals: Connect USB devices such as keyboards, mice, or other peripherals to the USB V2.0 ports.
  7. Serial Devices: If required, connect serial devices to the COM 1 port using appropriate cabling.
  8. Compact Flash Installation: Insert the Compact Flash card into its slot, ensuring it is correctly seated.
  9. Cable Routing: Route all cables to prevent strain, interference, and damage. Separate signal cables from power cables where possible.
  10. Environmental Considerations: Ensure the operating environment adheres to the specified temperature, humidity, and vibration limits for industrial panel PCs.
  11. Power On: After all connections are verified, re-energize the system and observe the NanoPanel PC's startup sequence.

FAQ

What is the primary function of the Siemens 6AV7881-3AA00-3DG0?
It serves as an industrial Human Machine Interface (HMI) and control platform, providing visualization and operational capabilities in automation systems.

What operating system is pre-installed on this NanoPanel PC?
The unit comes with Windows Embedded Standard 7 Service Pack 1 (WES 7 SP1) pre-installed on an 8 GB SIMATIC PC CompactFlash.

What software packages are included with the device?
It includes WinCC Advanced RT V13 (512 Power Tags, with logging and recipes) and a WinCC RT Advanced V14 License Package.

What are the power supply requirements for the NanoPanel PC?
The device requires a 24 V DC power supply for operation.

What type of display does the 6AV7881-3AA00-3DG0 feature?
It features a 12-inch Touch TFT display for interactive operation.
