Siemens 6AV7881-4AE00-7EA0 SIMATIC IPC277D Nanopanel PC

Description

The Siemens 6AV7881-4AE00-7EA0 is a SIMATIC IPC277D Nanopanel PC, designed for industrial human-machine interface (HMI) and control applications. This unit features a 15-inch Touch TFT display, providing an intuitive interface for operators. It is equipped with an Atom E660 (1.3 GHz) processor and 2 GB RAM, ensuring reliable performance for embedded tasks. Connectivity options include two 10/100/1000 Mbps Ethernet RJ45 ports, three high-current USB V2.0 ports (including a front-accessible USB), and one serial (COM 1) interface. For data storage, it includes a 50 GB SSD SATA (High Endurance) and a CompactFlash slot for expansion. The unit operates on a 24 V DC power supply and comes pre-installed with Windows 7 SP1, MUI (SSD), without SIMATIC software.

Features

• 15-inch Touch TFT Display
• Atom E660 (1.3 GHz) Processor
• 2 GB RAM
• 50 GB SSD SATA (High Endurance)
• Windows 7 SP1, MUI (SSD) Operating System
• 2x 10/100/1000 Mbps Ethernet RJ45 Ports
• 3x USB V2.0 Ports (High Current, including Front USB)
• 1x Serial (COM 1) Port
• CompactFlash Slot
• 24 V DC Power Supply

Applications

The SIMATIC IPC277D Nanopanel PC is suitable for a wide range of industrial applications requiring a compact, robust, and reliable HMI and control platform. Typical uses include:

• Machine operation and visualization
• Process control and monitoring
• Data acquisition and logging
• Embedded control systems
• Factory automation and manufacturing execution systems (MES)

Technical Specifications

Connections / Interfaces

Installation Guidelines

1. De-energize System: Ensure all power to the installation area and associated equipment is completely disconnected and locked out before beginning installation.
2. Mounting: Securely mount the Nanopanel PC into a suitable panel cutout or enclosure, ensuring proper ventilation and access to connections.
3. Power Connection: Connect the 24 V DC power supply to the designated terminals, observing correct polarity. Verify the power source meets the specified voltage requirements.
4. Grounding: Establish a robust protective earth (PE) connection to the device's grounding terminal to ensure electrical safety and minimize electromagnetic interference.
5. Ethernet Connections: Connect standard RJ45 Ethernet cables to the integrated ports for network communication.
6. USB and Serial Connections: Attach peripheral devices or communication cables to the USB V2.0 and serial (COM 1) ports as required by the application.
7. CompactFlash Installation: If using a CompactFlash card for additional storage or system images, insert it into the designated slot according to the device's orientation guides.
8. Cable Management: Route all cables neatly, separating power and signal cables to prevent interference. Use strain relief where necessary.
9. Environmental Considerations: Ensure the operating environment adheres to the specified temperature, humidity, and vibration limits to maintain optimal performance and longevity.
10. Power On and Configuration: After all connections are secure, re-energize the system and proceed with operating system and application software configuration.
