Siemens 6AV7882-0BA20-1BA0 SIMATIC IPC277E Panel PC

Description

The Siemens 6AV7882-0BA20-1BA0 is a SIMATIC IPC277E Nanopanel PC, designed for industrial applications requiring a compact and robust human-machine interface or control platform. This unit features a 9-inch Touch TFT display, an integrated Celeron N2807 processor, 4 GB of RAM, and an 80 GB SSD for reliable data storage. It comes pre-installed with WIN Embedded Standard 7E SP1 (English, 32-bit) and is delivered without SIMATIC software, allowing for flexible integration into various automation environments. Connectivity options include two 10/100/1000 Mbps Ethernet ports, one Display Port for external graphics, multiple USB interfaces (one USB 3.0, two USB 2.0), and one serial (COM 1) port, alongside a CFast slot for additional expansion. The unit operates on a 24 V DC power supply, making it suitable for standard industrial power systems.

Features

• 9-inch Touch TFT Display
• Integrated Celeron N2807 (2C/2T) Processor
• 4 GB RAM
• 80 GB Solid State Drive (SSD)
• Pre-installed WIN Embedded Standard 7E SP1 (English, 32-bit)
• 2x 10/100/1000 Mbps Ethernet RJ45 Ports
• 1x Display Port Graphic Output
• 1x USB 3.0 Port
• 2x USB 2.0 Ports
• 1x Serial (COM 1) Port
• CFast Slot for Expansion
• 24 V DC Power Supply Input

Applications

The Siemens SIMATIC IPC277E Panel PC is suitable for a range of industrial applications, including:

• Machine operation and control
• Human-Machine Interface (HMI) solutions
• Data acquisition and visualization
• Embedded control systems
• Manufacturing automation
• Process monitoring and supervision

Technical Specifications

Connections / Interfaces

Installation Guidelines

1. Safety First: Ensure all power to the installation area is de-energized before beginning any work. Verify with appropriate lockout/tagout procedures.
2. Mounting: As a Panel PC, this unit is typically designed for flush mounting into a control cabinet or machine panel. Ensure adequate space for ventilation and cable routing.
3. Power Connection: Connect the 24 V DC power supply to the designated power input terminals. Observe correct polarity to prevent damage. Use appropriately sized and shielded cables.
4. Grounding: Establish a proper protective earth (PE) connection to the chassis of the Panel PC. This is crucial for electrical safety and electromagnetic compatibility (EMC).
5. Network Connections: Connect Ethernet cables to the RJ45 ports for network communication. Use shielded cables in industrial environments to minimize interference.
6. Peripheral Connections: Connect USB devices, serial devices, and the Display Port monitor as required. Ensure cables are routed to avoid strain and interference.
7. CFast Installation: If using a CFast card, insert it into the designated slot, ensuring correct orientation.
8. Environmental Considerations: Install the Panel PC in an environment that complies with its specified operating temperature and humidity ranges. Ensure proper airflow for cooling.
9. Cable Management: Route all cables neatly and securely, separating power cables from signal cables to reduce potential interference.
10. Power On: After all connections are secure and verified, re-energize the power supply to the system.
