Siemens 6ES7647-6BG26-0WF0 SIMATIC BOX PC 627B Industrial PC

SKU 6ES7647-6BG26-0WF0

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6ES7647-6BG26-0WF0
Country of origin:Germany
Product Type: Industrial PC
Barcode: 85371091
Payment: T/T, Western Union
Weight: 7000g
Dimensions: 120.5 x 50.5 x 10.0 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6ES7647-6BG26-0WF0 is a SIMATIC BOX PC 627B designed for robust industrial applications. This unit is equipped with an Intel Core 2 Duo T7400 2.16 GHz processor, 1 GB of DDR2 RAM, and a 24 V DC industrial power supply. It provides extensive connectivity with dual Gigabit Ethernet ports, four high-current USB 2.0 ports, and a serial COM port. The system features onboard graphics with 128 MB of shared memory and includes an integrated RAID controller. For storage, it is configured with two CompactFlash drive slots, one front-accessible and one internal, and is supplied with Windows XP Embedded on a 2 GB CompactFlash card.

Features

Intel Core 2 Duo T7400 processor at 2.16 GHz
1 GB DDR2 667 SODIMM memory
Dual 10/100/1000 Mbit/s Ethernet ports for network redundancy or separation
Four high-current USB 2.0 ports for peripheral devices
Onboard RAID controller for data integrity
Integrated monitoring for watchdog, temperature, and fan status
Two available PCI slots for hardware expansion
Operates on a 24 V DC industrial power supply

Applications

Process visualization and HMI stations
Data acquisition and logging systems
Industrial control and automation gateways
Machine vision and quality control systems
Shop-floor data collection terminals

Technical Specifications

Specification	Value
Manufacturer	Siemens
Product Series	SIMATIC BOX PC 627B
Processor	Intel Core 2 Duo T7400 (2.16 GHz, 4 MB L2 Cache, 667 MHz FSB)
Memory (RAM)	1 GB DDR2 667 SODIMM
Graphics	Onboard, 128 MB Shared Memory
Ethernet Interface	2 x 10/100/1000 Mbit/s RJ45
USB Interface	4 x USB 2.0 (High Current)
Serial Interface	1 x COM1
Storage Controller	Onboard RAID Controller
Storage Drive 1	Front-side CompactFlash Drive (without CF card)
Storage Drive 2	Internal CompactFlash Drive (installed instead of HDD/ODD, without CF card)
Operating System	Windows XP Embedded (SP2) English on 2 GB CompactFlash
Expansion Slots	2 x PCI (Free)
Power Supply	24 V DC
System Monitoring	Watchdog, Temperature, Fan Monitoring
Product Lifecycle Status	Obsolete
Country of Origin	Germany (Estimate)
Package Dimensions	120.5 x 50.5 x 10.0 cm
Shipping Weight	7.00 kg

Installation Guidelines

CRITICAL WARNING: Risk of Electric Shock and Equipment Damage

Disconnect all power sources before installation or maintenance. This device contains components sensitive to electrostatic discharge (ESD). Use appropriate ESD protection, including wrist straps and mats, when handling. Failure to comply can result in equipment damage and personnel injury.

1 Site Preparation: Select a mounting location within an enclosure that provides adequate ventilation and protection from excessive vibration, moisture, and contaminants. Ensure sufficient clearance around the unit for airflow and cable access.
2 Mounting: Securely fasten the Box PC to the mounting panel using all provided mounting points. Ensure the chassis is level and stable to prevent mechanical stress.
3 Grounding: Connect the chassis ground terminal to the main panel's protective earth (PE) bus bar using a low-impedance conductor. A reliable ground connection is essential for safety and noise immunity.
4 Power Connection: Connect the 24 V DC power supply to the designated input terminals. Verify the polarity is correct before energizing the circuit. Use appropriately sized wiring for the load and distance.
5 I/O and Peripheral Wiring: Connect Ethernet, USB, serial, and any other required cables. Route signal cables separately from power cables to minimize electromagnetic interference. Ensure all connectors are fully seated.
6 Final System Check: After all connections are made, re-verify wiring against schematics. Apply power to the unit and check for correct boot sequence and status indicators. Proceed with software configuration as required.
