Beckhoff IP2000-B400 Fieldbus Box

Apenas 10 item(ns) restante(s) em estoque

Fabricante: BECKHOFF
Nº do Produto: IP2000-B400
País de origem:Alemanha
Tipo de Produto: Fieldbus Boxes
Pagamento: T/T, Western Union
Peso: 350g
Dimensões: 30 mm x 210 mm x 26.5 mm
Porto de embarque: Xiamen
Garantia: 12 meses

Description

Designed for distributed industrial automation environments, the IP2000-B400 serves as a robust Interbus fieldbus box featuring 8 digital output channels. This low-profile module enables direct connection of binary control signals from the Interbus network to actuators, contactors, solenoid valves, and indicator lamps. Engineered with a highly resilient polyamide housing, the device allows for direct mounting on machines and process equipment without requiring an additional protective control cabinet.

The IP2000-B400 manages decentralized digital output processing with high-speed performance, achieving an approximate 1 ms data transfer time when operating up to 10 modules. The integration of standard M8 and M23 connections ensures stable mechanical and electrical interfaces under demanding factory floor conditions.

Features

8-channel digital output layout handling up to 0.5 A per channel.
Integrated Interbus communication interface with data transfer speeds up to 500 kBaud.
Short-circuit protected digital outputs with an auxiliary power configuration.
Robust IP65/66/67 rating for superior resistance to moisture, dust, and environmental contaminants.
Standardized M23 connections for secure, vibration-resistant bus cabling.
Compact 30 mm width optimization for tight physical mounting spaces.

Applications

Automotive assembly lines and robotic welding cells.
Conveyor systems and high-throughput material handling.
Packaging machinery and automated bottling plants.
De-centralized field I/O processing in harsh processing environments.

Technical Specifications

Manufacturer	Beckhoff
Part Number / Model	IP2000-B400
Fieldbus Protocol	Interbus
Number of Outputs	8
Output Connections	8 mm, snap-type
Load Type	Ohmic, inductive, lamp load
Nominal Output Voltage	24 V DC (-15% / +20%)
Maximum Output Current	0.5 A per channel (individually short-circuit proof)
Short-Circuit Current	Typically 1.5 A
Data Transfer Rate	500 kBaud
Cable Length	Maximum 400 m between modules
Power Supply Connection	Feed: 1 x M8 male socket (4-pin); Downstream: 1 x M8 female socket (4-pin)
Bus Interface	1 x M23 female socket (9-pin), 1 x M23 male socket (9-pin)
Box Supply Current	85 mA + sensor consumption (max. 0.5 A)
Material	PA6 (polyamide)
Dimensions (W x H x D)	30 mm x 210 mm x 26.5 mm
Operating Temperature	0 to +55 degC
Storage Temperature	-25 to +85 degC
Protection Rating	IP65/66/67 (conforms to EN 60529)
Weight	Approx. 350 g

Connections and Interfaces

Interface Type	Connector Style	Pin Count	Function
Power Supply (Feed)	M8 Male	4-pin	Control voltage and load voltage input
Power Supply (Downstream)	M8 Female	4-pin	Power distribution to subsequent modules
Bus Interface (In)	M23 Male	9-pin	Interbus network incoming connection
Bus Interface (Out)	M23 Female	9-pin	Interbus network outgoing connection

Installation Guidelines

Mount the module securely using the two integrated 3.5 mm diameter fixing holes intended for M3 screws.
Ensure all M8 and M23 connectors are fully tightened to their specified torques to maintain the IP67 protection integrity.
Verify that the external 24 V DC power source matches the designated nominal voltage and current requirements.
Keep bus communication cables separate from high-power AC lines to reduce potential electromagnetic interference.

Compliance and Certifications

EMC Immunity: Conforms to EN 61000-6-2
EMC Emission: Conforms to EN 61000-6-4
Vibration Resistance: Conforms to EN 60068-2-6
Shock Resistance: Conforms to EN 60068-2-27

Product Image	Model Number / Title	Condition	Availability	Action
	IE2808 BECKHOFF Caixa de Extensão de Saída Digital de Alta Densidade de 16 Canais	Original New	In Stock	View Details

Key Features:

What is the primary function of the Beckhoff IP2000-B400 module?

The Beckhoff IP2000-B400 is an Interbus fieldbus box featuring 8 digital output channels designed to transmit binary control signals directly to field actuators without requiring an enclosure.

What is the maximum output current rating per channel?

Each of the 8 digital output channels supports a maximum current of 0.5 A and includes individual short-circuit protection.

What connectors are used for the bus interface?

The bus interface is equipped with one 9-pin M23 male connector and one 9-pin M23 female connector.

What environmental protection rating does this module carry?

The IP2000-B400 features an IP65/66/67 rating, making it highly resistant to dust, spray water, and immersion.

What is the operating temperature range for this Fieldbus Box?

The device operates reliably in temperatures ranging from 0 to +55 degC.
